Specifications
Brand Name :
HITIACH
Model Number :
TX23D38VM0CAA
Certification :
ISO9001
Place of Origin :
JAPAN
MOQ :
1PCS
Payment Terms :
TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :
600PCS
Delivery Time :
1-2 DAYS
Packaging Details :
STANDARD PACKING
MODEL NUMBER :
TX23D38VM0CAA
BRAND :
HITACHI
SIZE :
9.0"inch
RESOLUTION :
800(RGB)×480 [WVGA] 104PPI
BRIGHTNESS :
500 cd/m² (Typ.)
TEMPERATURE RANGE :
Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
Viewing Angle :
85/85/85/85 (Typ.)(CR≥10
Description

HITACHI TX23D38VM0CAA Application Details

Basic Information : Brand Model TX23D38VM0CAA
Type LCM a-Si TFT-LCD Used For


Screen Size 9.0" Alias -
Environment : Storage Temp. -30 ~~ 80 °C Operating Temp. -20 ~~ 70 °C
RoHS Vibration 2.0G (19.6 m/s²)

HITACHI TX23D38VM0CAA Mechanical Details

Pixel Features : Resolution 800(RGB)×480, WVGA Dot Pitch(mm) 0.08125×0.24375 (H×V)
Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.24375×0.24375 (H×V) [104PPI]
Mechanical Size : Active Area(mm) 195(H) × 117(V) Bezel Area(mm) 197.0(H) × 119.0(V)
Outline Dim.(mm) 218(H) × 135(V) Depth(mm) 11.15±0.3
Outline Features : Form Style Flat Rectangle Outline Shape
Aspect Ratio 15:9 (H:V) Orientation Landscape type
Mounting : Rear mounting holes (4-Ф2.88)
Other Spec : Weight 330g (Typ.) Treatment

HITACHI TX23D38VM0CAA Optical Details

Basic Information : Luminance(cd/m²) 500 (Typ.) Contrast Ratio 800:1 (Typ.) (Transmissive)
Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Display Mode IPS, Normally Black, Transmissive
Best View on Symmetry Response(ms) 25 (Typ.)(Tr+Td)
Color Performance : White Coordinate X:0.350; Y:0.360 Display Colors 262K/16.7M (6-bit / 6-bit + Hi-FRC)
Color Temperature 4855K White Uniformity 1.33 (Max.)(9 points)
1931 Color Gamut : NTSC Ratio 60% sRGB 74% coverage
Adobe RGB 59% coverage DCI-P3 62% coverage
Rec.2020 45% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

HITACHI TX23D38VM0CAA Electronics Details

Frame Rate : 60Hz
Reverse Scan : No
Power Consumption : 8.46W (Typ.)

HITACHI TX23D38VM0CAA Interface Details

Signal Electrical : Voltage Supply 3.3V (Typ.) Current Supply 465/560mA (Typ./Max.)
Consumption 1.5W (Typ.)
Signal Type : LVDS (1 ch, 6/8-bit) Signal Voltage -
Interface Features : Position - Type Connector
Interface Detail : Brand Model Quantity Pins Pitch Pin Configuration
JAE FI-SEB20P-HF13E 1 pcs 20 pins 1.25 mm LVDS-20P1C8B-110A

HITACHI TX23D38VM0CAA Backlight Details

Backlight Features: Shape - Type WLED Position Edge light type
Replacement - Quantity 3S7P Life Time 70K(Typ.) (Hours)
Interface Features : Position - Type Connector
Interface Detail : Brand Model Quantity Pins Pitch Pin Configuration
JST SM08B-SRSS-TB 1 pcs 8 pins 1.0 mm BDE-8PINS-VVVNNGGG
Backlight Driver : With LED Driver
Driver Electrical : Voltage Supply 12.0V (Typ.) Current Supply 580±40mA
Consumption 6.96W (Typ.)

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 195(W)×117(H) mm, outline size of 218(W)×135(H)×11.45(D) mm, viewing area size of 197.0(W)×119.0(H) mm, net weight of 330g (Typ.). As a IPS, Normally Black, Transmissive LCM product, TX23D38VM0CAA can provides 500 cd/m² display brightness 800:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 25 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 6-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 262K/16.7M colors, also with performance of color gamut 60% (NTSC). This product adopted 3S7P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 70K hours, With LED Driver. TX23D38VM0CAA utilizes LVDS (1 ch, 6/8-bit) as it's signal inputting systerm, which connected by 20 pins Connector with power supply voltage of 3.3V (Typ.)
