GB/T 2679.5 MIT Folding Endurance Tester For Paper Board
GB/T 2679.5 MIT Folding Endurance Tester For Paper Board
GB/T 2679.5 MIT Folding Endurance Tester For Paper Board
GB/T 2679.5 MIT Folding Endurance Tester For Paper Board
Specifications
Brand Name :
GESTER
Model Number :
GT-N16
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets/month
Delivery Time :
10-30 days
Packaging Details :
wooden packaging
Product name :
Mit Folding Endurance Tester
Warranty :
1 Year
Certificate :
CE ISO
Application :
paper and boards
Measuring Range :
0 - 99999
Feature :
reliable, professiona
Price :
Factory Price
Color :
Gray
Description

MIT Folding Endurance Tester For Paper Board

Introduction


GT-N16 MIT Type Paper Folding Endurance Tester has various functions, such as, parameter testing, parametric transformation, parameter regulation, parameter display, parameter memory and parameter print. The tester has data processing function which can directly output result of statistical
data with convenient operation, easy regulation and stable performance. The main functions are shown as following , compact structure, light weight, abundant functions, horizontal type and stable performance, so the tester is suitable for different paper and boards.

Standards


ISO 5626, GB/T 2679.5, QB/T 1049

Key Specification

Measuring Range 0 - 99999
Folding Angle 135±2°, Folding Frequency: 175±10 times/min.
Folding Head Width 19±1mm; Folding Radius: 0.38±0.02mm.
The spring tension 4.91N~14.72N, when every 9.81N tension is added, the compression of spring is 17 mm reduced at least.
The clearances between folding ports 0.25, 0.50, 0.75 and 1.00mm (four ranges)
The tension change due to the eccentric rotating of clamping folding head Should not be larger than 0.343N.

Product Image
