200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
200 N Bending Stiffness Tester Shoe Testing Machine For Whole Shoes
Specifications
Brand Name :
GESTER
Model Number :
GT-KA16
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets/month
Delivery Time :
10-30days
Packaging Details :
wooden packaging
Power :
AC220V/50Hz
Usage :
measure bending resistance of whole shoes
Warranty :
12 Months
Product name :
Shoe Stiffness Testing Machine
Application :
shoes
Color :
Silver/Black
Quality :
High,good
Description

Shoe Testing Machine whole shoes Bending Stiffness Tester

Product Introduction

Application:

Shoes Bending Stiffness Tester is used to measure bending resistance of whole shoes (France shoe Size 39, 42,and British shoe Size 6,Size 8). Clamp the foreshoes (confirming to 1/3 of palm shoes, located on shaft location), after motor launching, driving to pulley, to make shaft drive the turning board at 100mm/min to impose the strength of 30N to shoes in order to do test.

Standards:

GB/T 20991 section 8.4.1

ISO 20344-2020 section 8.5

AS/NZS 2210.2 section 8.4.1

ISO 17707 section 4.2

Feature
1.LCD control, easy operate, and display results digitally.

2.Equip with a decoder on shaft, and inducting angle speed of turning board, showing the value through the display with accuracy of 0.1°.

Key Specifications

Model

GT-KA16

Capacity

200 N

Bending speed

100mm/min (adjustable)

Sample size

French standard: Size 39, 42 ; British standard : Size 6, 8

Test load

30 N

Bending position

1/3 of shoes

Angle resolution

0.1°

Force resolution

1/50000

Measurement method

Fixed fore to display angle

Fixed angle to display force

Power

1∮AC 220V 50/60HZ 3A

Dimension (W×D×H)

50×45×53 cm

Weights

40kg

Standards

GB/T 20991 section 8.4.1

ISO 20344-2020 section 8.5

AS/NZS 2210.2 section 8.4.1

ISO 17707 section 4.2
