2.92mm Female to 2.92 Female Flange Panel mount Precision RF Adapter
2.92mm Female to 2.92 Female Flange Panel mount Precision RF Adapter
2.92mm Female to 2.92 Female Flange Panel mount Precision RF Adapter
2.92mm Female to 2.92 Female Flange Panel mount Precision RF Adapter
Specifications
Brand Name :
Terui
Model Number :
2.92-KFKG
Certification :
RoHS
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1000000pcs per month
Delivery Time :
3-10 working days
Packaging Details :
Standard export packaging
Description

2.92mm Female to 2.92 Female Flange Panel mount Precision RF Adapter

2.92mm Precision RF Adapter have two kinds of material , includes brass and stainless steel. Both of them are RoHS and Reach Compliant . They are widely used in the modem precision measurement and microwave communication equipment

Product Details

2.92mm Female to 2.92 Female Flange Panel mount Precision RF Adapter

Teruilai P/N: 2.92-KFKG

RoHS Certificate: Compliant

Interface Standard:MIL-STD-348A

Electrical data Requirments
Frequency range DC-40GHZ
Characteristic impedance 50Ω
VSWR ≦1.25:1
Mechanical data Requirments
Durability (matings) ≧500
Environmental data Requirments
Temperature range -45℃ to 85℃
Material data Requirments
Connector parts Material Plating
Body Stainless steel (Su303),passivated
Pin contacts Beryllium-Copper Gold-plated
Insulators PEI
