PT-8S Digital Rotational Viscometer
PT-8S Digital Rotational Viscometer
PT-8S Digital Rotational Viscometer
PT-8S Digital Rotational Viscometer
PT-8S Digital Rotational Viscometer
PT-8S Digital Rotational Viscometer
PT-8S Digital Rotational Viscometer
PT-8S Digital Rotational Viscometer
PT-8S Digital Rotational Viscometer
PT-8S Digital Rotational Viscometer
Specifications
Model Number :
PT-8S
Model :
PT-8S
MOQ :
Negotialble
Payment Terms :
Negotialble
Brand Name :
Pootab
Timed Measurement Function :
Available
Place of Origin :
Guangdong
Operation Interface :
Chinese / English
Certification :
CE / IS09001
Measuring Range :
1 ~ 2×10⁶ mPa·s
Price :
Negotialble
Packaging Details :
Negotialble
Description

PT-8S Digital Rotational Viscometer

Features:

1. This instrument is a digital viscometer, where the motor drives the rotor at a constant speed via a speed reducer. When the rotor rotates in the liquid, the liquid generates a viscous torque acting on the rotor—the greater the viscosity of the liquid, the larger this viscous torque becomes; conversely, the smaller the viscosity of the liquid, the smaller the viscous torque. The viscous torque acting on the rotor is detected by the sensor and processed by the computer to determine the viscosity of the measured liquid.

2. This instrument utilizes microcomputer technology, allowing for convenient range setting (rotor number and speed). It digitally processes data detected by the sensor and clearly displays on the screen the set rotor number, speed, viscosity value of the measured liquid, and its full-scale percentage during measurement.
3. The instrument is equipped with four rotors (No. 1, 2, 3, and 4) and eight speed settings (0.3, 0.6, 1.5, 3, 6, 12, 30, and 60 revolutions per minute), forming 32 combinations to measure the viscosity of various liquids within the specified range.
Item Specification
Measuring Range 1 ~ 2×10⁶ mPa·s
Rotor Specifications Rotors No.1–4; Optional No.0 rotor for low viscosity measurement down to 0.1 mPa·s
Rotor Speed 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 rpm
Auto Mode Automatically selects the appropriate rotor number and speed
Operation Interface Chinese / English
Reading Stability Cursor The reading is basically stable when the vertical bar block cursor is fully filled
Measurement Accuracy ±2% (for Newtonian liquids)
Power Supply AC 220V±10%, 50Hz±10%
Operating Environment Temperature: 5℃~35℃, relative humidity ≤80%
Overall Dimensions 370×325×280 mm
