Electronic Stability Environment Constant Temperature And Humidity Test Chamber 100L
Electronic Stability Environment Constant Temperature And Humidity Test Chamber 100L
Electronic Stability Environment Constant Temperature And Humidity Test Chamber 100L
Electronic Stability Environment Constant Temperature And Humidity Test Chamber 100L
Specifications
Brand Name :
GSKA
Model Number :
Environmental Test Chamber
Certification :
CE SGS ROHS UL CE
Place of Origin :
Dongguan China
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
T/T, L/C
Supply Ability :
100 Set / Sets per Month
Delivery Time :
10-60days after confirmed payment or by contract stipulation
Packaging Details :
Export package
External Size :
W78*H157*D105cm
Internal Material :
1.2mm Thick SUS#304
controller :
digital controller from South Korea
Temperature uniformity :
±2.0℃
Customized support :
OEM
Power :
220V , 50Hz
Condenser :
Water-cooled condensing agent
Keyword :
Environmental Chambers
Description

Electronic Stability Environment Climate Constant Temperature And Humidity Test Chamber 100L

Product Features:

(1)The outer case is made up of SUS304 steel plate.CNC processing molding,Beautiful design,Reacionless holder,easy operation


(2)Large LCD touching screen


(3)Adopt micro-computer temperature humidity controller.accuracy and reliability


(4)Large watching window;floodlight,of which can keep inside of chamber light;3 layers of vacuum glasses;can observe the status at any time


(5)Individual temperature limitation alarm system;automatically cut off when exceed temperature limitation;which can assure the safe testing


(6)Equipped with the testing hole with the diameter of 50mm at the both side of testing chamber.can be connected with outer power cable or signal cable


(7)Adopt high quality fixed PU running wheel in the bottle of machine


(8)New program temperature humidity chamber can save power more than 45% compared than the traditional type.can save responding time be around 50%.can deduct water consumption be around 80%

Test Chamber Design Features:
1. High performance and quiet operation (68 dBA)

2. Space-saving designed for flush installation to wall

3. Full thermal break around doorframe

4. One 50mm diameter cable port o left, with flexible silicone plug

5. Accurate wet/dry-bulb humidity measurement system for easy maintain

Performance parameters:

Temperature
Model G100 G150 G200 G400 PG800 G1000
Inner chamber size W×H×D(cm) 50×50×40 50×60×50 60×75×50 80×85×60 100×100×80 100×100×100
Exterior chamber size W×H×D(cm) 78×157×105 78×167×115 88×185×115 108×195×125 128×210×145 128×210×165
Testing temperature range 0ºC,-20ºC,-40ºC,-70ºC~180ºC
Testing humidity range 10%RH~98%RH
Temp.humi.fluctuation ±0.3ºC;±0.5%RH
Temp.humi.uniformity ±2ºC;±3% empty loading after stablize for 30mins ±2ºC;±3%RH
Temp.humi.resolution 0.01ºC;0.1%RH
Heating&cooling time ºC/min Heat-up:3ºC/min(average),cool-down:1ºC/min(average)
Exterior chamber material Cold rolled plate + Powder coating
Interior chamber material SUS#304 Stainless steel
Insulation material Rigid Polyurethane foam
Circulation system Centrifugal fan air circulation system
Heating system SUS# Stainless steel high-speed heater
Humidification system Electrothermal steam humidification
Dehumidifying ADP critical dew point cooling / dehumidifying method
Refrigeration system Finned evaporator + Air(Water) cooling condenser
Controlling system Touch screen controller
Other components Vacuum glass observation window
Test hole(100mm)
Controller status indicator
View light
Compartment shelf (2 freely adjustable)
Safety protection device Overheat protection circuit breaker
Humidification system overheat protection
Compressor overload protection
Control system overload protection
overload indicator
Phase sequence protection
Water shortage protection
High voltage and low voltage protection
Over temperature protection
Water supply delay protection
Fan overcurrent protection
Power supply AC 1ψ220V;3ψ380V 60/50Hz
Customization service Non-standard or special requirements are all welcome


Electronic Stability Environment Constant Temperature And Humidity Test Chamber 100L

Customer Support Services:


Ø Installation


Ø Training (Training customer employees)


Ø Calibration


Ø Preventative maintenance


Ø Replacement parts


Ø Assistance via phone or internet


Ø On-site diagnosis and repair/online diagnosis and repair
