M5 NTC Thermistor-Probe Assembly with Ring Lug
M5 NTC Thermistor-Probe Assembly with Ring Lug
M5 NTC Thermistor-Probe Assembly with Ring Lug
M5 NTC Thermistor-Probe Assembly with Ring Lug
M5 NTC Thermistor-Probe Assembly with Ring Lug
M5 NTC Thermistor-Probe Assembly with Ring Lug
Specifications
Model Number :
MFP
Certification :
ROHS
Place of Origin :
Hefei, Anhui province, China
MOQ :
2000pcs
Price :
USD1.2/pc
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000pcs/month
Delivery Time :
20-25days
Packaging Details :
standard export packing
Rohs Compliant :
Yes
Operating Temperature Range :
-40 to 125°C
Supply Current :
0.5 mA
Resistance Range :
0.3kΩ to 2000kΩ
Wire :
XLPE UL4484 26AWG 7/0.16TS OD1.05*2.2
Material :
Ceramic
housing :
ring lug M2/M4/M6/M8
Mounting Type :
surface mount
Encapsulation :
Epoxy resin encapsulated
Optical Resolution :
20:1
Output Type :
Analog
Head Material :
Cu, Cu/ Sn, Cu/ Ni, Nylon...Tube
Supply Voltage :
2.7 to 5.5 V
Power Consumption :
1.5mW
Insulation Resistance :
≥100MΩ 500VDC
Description

M5 NTC Thermistor-Probe Assembly with Ring Lug

Product description

The item is one M5 NTC Thermistor-Probe Assembly with Ring Lug

NTC Thermistor-Probe Assemblies for temperature sensing and measurement.

Our NTC thermistor probe assemblies are manufactured from a specially formulated metal oxide ceramic material that is extremelly accurate in sensing temperature. Available in a variety of housings with custom design capabilities, PANR probe assemblies are suited best for transformers, electric motors, air sensors, and HVAC systems. M5 NTC Thermistor-Probe Assembly with Ring Lug

Product Features

• Ring lug terminals enable easy and secure surface mounting

• Completely customizable; offer a variety of housings and lead wire gauges

• Fast response times

• Provide a high-stability replacement for PT100 thermocouples; experience minimal drift from their initial electrical values

• M5 NTC Thermistor-Probe Assembly with Ring Lug

Drawing&Dimensions

M5 NTC Thermistor-Probe Assembly with Ring Lug

• Isolation voltage to 2.2kV

• Resistance at 25℃ from 10kΩ to 250kΩ

• Beta value from 3,000K to 4,500K

• Dissipation constant of 3 mW/℃

• Thermal time constant of 40.0 s

• Max. power of 125mW

• Mounting hold diameter of 3.7mm or 4.4mm

Product image

M5 NTC Thermistor-Probe Assembly with Ring Lug

M5 NTC Thermistor-Probe Assembly with Ring Lug

M5 NTC Thermistor-Probe Assembly with Ring Lug
