RTD Sensor Helmet Mounted Temperature Transmitter TMT187A
RTD Sensor Helmet Mounted Temperature Transmitter TMT187A
Specifications
Brand Name :
SENSE
Model Number :
TMT187A
Certification :
iHART
Place of Origin :
Shanghai China
MOQ :
10PCS
Payment Terms :
T/T
Supply Ability :
10000PCS / Month
Delivery Time :
5-8 workdays
Packaging Details :
Carton packing
Price :
Negotiate
Temperture Accuracy :
0.1C
Designs :
Pt100 Pt1000
Sensor Type :
RTD
Power Supply Range :
24V (standard)
Accuracy :
±0.075% of span
Input Power :
24V DC
Output :
4-20mA
Stability :
<0.05%/year
Mounting Type :
Head mounted
Response Time :
≤ 1 second
Description
RTD Helmet-mounted temperature transmitter TMT187A
Application areas
Head mounted temperature transmitter with iHART- protocol for converting various input signals into a
scalable 4 to 20 mA analogue output signal
Power supply
Supply voltage 7.5 to 45 VDC , polarity protected
Output
Output signal 4 to 20 mA
Signal on alarm Underranging Linear drop to 3.8 mA
Overranging linear rise to 20.8 mA
Sensor break;
sensor short-circuit(not for thermocouples TC) :3.6mA or 22 mA
Load Max.(Vpower supply-7.5 V)/0.022 A
Linearisation/transmission behaviour Temperature linear
Installation conditions
Installation instructions Installation angle:no limit
Installation area:connection head according to DIN 43 729 Form B;
TAF 10

Performance characteristics
Response time 1 s
Reference operating conditions Calibrationtemperature: 23℃(73.4F)5Ko
Long-term stability <0.05%/year
Switch on delay <5S
In Negligible
Load in Negligible
Maximum measured error Input Type Measurement accuracy
RTD Pt100 0.2K or 0.08%
Pt1000 0.3K or 0.12%
Environment conditions
Ambient temperature limits -40℃ to 85℃(-40℉ to 185℉)
Storage temperature -50℃ to 100℃(-58℉ to 212℉)
Condensation Allowable
Degree of protection IP00,IP66(installed)
Shock and vibration resistance 4g/2 to 150 Hz as per IEC 60 068-26
Electromagnetic Interference immunity and interference emission according
compatibility(EMC) to GB/T17626.2-1998, compliance with IEC 61000-4-3:1995
Others
Dimensions Dia. 44 mmX24 mm
Weight Approx. 34g
Material Housing: PC
Potting: epoxy
