ASTM E10 Portable Hydraulic Brinell Hardness Tester iPHB-3000 Max Force 3000Kgf
ASTM E10 Portable Hydraulic Brinell Hardness Tester iPHB-3000 Max Force 3000Kgf
Specifications
Brand Name :
iqualitrol
Model Number :
iPHB-3000
MOQ :
1 Set
Payment Terms :
T/T
Supply Ability :
10 sets per month
Delivery Time :
10 Working Days
Packaging Details :
Carton Box
iPHB-3000 :
3000kgf (option: 500kgf, 750kgf, 1000kgf, 1500kgf)
Indenter :
φ10mm Cemented Carbide Steel Ball (option: 5mm)
Vertical space :
320mm (Supports Customization)
Depth throat :
100mm
Pressing Structure :
Based On Hydraulic Principles
Application :
Testing Metal Materials With Uneven Structures Or Coarse Grains
Description

ASTM E10 Portable Hydraulic

Brinell Hardness Tester iPHB-3000 Max Force 3000Kgf

Download Technical Data: Hydraulic Brinell Hardness Tester iPHB-3000

Main Features:

The iPHB-3000 has a large indentation area, which can reflect the average hardness influenced by the various components of the metal over a larger range and is not affected by individual phases or local inhomogeneities.

The pressing structure is based on hydraulic principles, with simple manual operation and convenient portability.

The iPHB-3000 is very suitable for testing metal materials with uneven structures or coarse grains. The on-site test results are real, accurate, reproducible, and can precisely test medium to large workpieces.

It has high indication accuracy, a wide testing range, can use multiple experimental forces, and allows the selection of various ball indenters.

The test conditions and measurement accuracy comply with GB/T231.2, TSO6;506-2, and ASTM E10 standards.

Technical Specifications:

Hardness Range 15.9-653 HBW
Test Force 3000kgf (option: 500kgf, 750kgf, 1000kgf, 1500kgf)
Indenter φ10mm Cemented carbide steel ball (option: 5mm)
Test Height 320mm (Supports customization)
Depth 100mm
Dimension 580*200*560mm, packing: 400*360*690mm
Weight 15Kg, gross 22Kg

ASTM E10 Portable Hydraulic Brinell Hardness Tester iPHB-3000 Max Force 3000Kgf
