Digital Force Gauge FM-204-100K
Digital Force Gauge FM-204-100K
Digital Force Gauge FM-204-100K
Digital Force Gauge FM-204-100K
Specifications
Brand Name :
iqualitrol
Model Number :
FM-204-100K
Certification :
CE
Place of Origin :
DONGGUAN
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100 sets per month
Delivery Time :
10 work days
Packaging Details :
Carton box
Force Range :
±100 kgf /±980 N /±220 Lbf
Resolution :
0.01 kgf/ 0.1 N/ 0.1 Lbf
Accuracy :
±0.5%FS±1Digit
Measurement State :
Peak Value Measurement,Real Time Measurement
Display :
2 Reversed 4Digit LCD
Power Off :
10 Minutes Auto Power Off, Manual Power Off
Description

Spec:The digital force gauge is a kind of simple and convenient functional instrument for high-accuracy push force and pull force test.It is widely used in electronics,building hardware,textile,auto parts,

Features

* High accuracy and high resolution.

* Digital display with no guessing or errors.

* With 4 measurement unit for selection and conversion, N, kg, lb, g.

* With peak value hold function.

* With 10 minutes auto power off and manual power off.

* Power can be supplied by either alkaline battery or 6V DC power.

Specifications

Force Range ±100 kgf
±980 N
±220 Lbf
Resolution 0.01 kgf
0.1 N
0.1 Lbf
Accuracy ±0.5%FS±1Digit
Unit kgf,gf,N,Lbf
Measurement State Peak Value Measurement,Real Time Measurement
Display 2 Reversed 4Digit LCD
Power Off 10 Minutes Auto Power Off, Manual Power Off
Backlight Blue Backlight
Safe Load 150%FS(Buzzer Alarm Over 110%FS)
Power Supply 2X1.5 AA(UM-3)Battery or 6VDC Power Supply
Operating Temperature:0~40ºC
Conditions Humidity:<80%
Surrounding No Vibration Source or Corrosive Medium Around
Weight 390g
Size 211x80x36mm

Accessories

Standard Accessories Digital Force Gauge
Pulling Hook
Flat Tip
Cone Tip
V-shaped Groove Tip
V-shaped Wedge Tip
Lengthening Connection Rod Screw Rod
Cap Nut
Manual
Carrying Case
Optional Accessories Power Adapter

Specifications And Application Of Accessories
