Digital Force Gauge FM-207-1k
Digital Force Gauge FM-207-1k
Specifications
Brand Name :
iqualitrol
Model Number :
FM-207-1k
Certification :
CE
Place of Origin :
DONGGUAN
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100 sets per month
Delivery Time :
10 work days
Packaging Details :
Carton box
Accuracy :
0.2% FS 1 Digit
Unit :
Kgf, gf, N, Lbf
Display :
2 Reversed 4 Digit LCD
Safe Load :
150% FS ( Buzzer Alarm Over 110% FS )
Data Output :
USB, Bluetooth
Power Supply :
2 x 1.5 AA( UM-3 ) Battery or 6VDC Power Supply
Description

Spec:The digital force gauge is a kind of simple and convenient multi-functional instrument for high-accuracy push force and pull force test. It is widely used in electronics, building hardware, etc.

Features

* High accuracy and high resolution.

* Digital display with no guessing or errors.

* With 4 measurement unit for selection and conversion, N, kg, lb, g.

* With peak value hold function.

* With data memory function, can memorize 99 groups of data.

* With 10 minutes auto power off and manual power off.

* Power can be supplied by either alkaline battery or 6V DC power.

* Use USB/RS-232 data output to connect with PC.

* Provide Bluetooth data output choice.

Specifications

Force Range 1 kgf
1000 gf
9.8 N
2.2 Lbf
Resolution 0.001 kgf
1 gf
0.001 N
0.001 Lbf
Accuracy 0.2% FS 1 Digit
Unit Kgf, gf, N, Lbf
Measurement State Peak Value Measurement, Real Time Measurement
Display 2 Reversed 4 Digit LCD
Power Off 10 Minutes Auto Power Off, Manual Power Off
Backlight Blue Backlight
Safe Load 150% FS ( Buzzer Alarm Over 110% FS )
Data Output USB, Bluetooth
Power Supply 2 x 1.5 AA( UM-3 ) Battery or 6VDC Power Supply
Operating Conditions Temperature: 0 ~ 40℃
Humidity: <80%
Surrounding No Vibration Source or Corrosive Medium Around
Weight 390 g
Size 211 x 80 x 36 mm

Accessories

Sandard Accessories Digital Force Gauge
Pulling Hook
Flat Tip
Cone Tip
V-shaped Groove Tip
V-shaped Wedge Tip
Lengthening Connection Rod Screw Rod
Cap Nut
Manual
Carrying Case
Optional Accessories CD
USB Data Cable
Bluetooth Adapter
Power Adapter
Force Gauge Stand

Specifications And Application Of Accessories


Digital Force Gauge FM-207-1k
