Specifications
Brand Name :
Temei
Model Number :
T9-L1390S
Place of Origin :
china shenzhen
MOQ :
1
Price :
5999usd~10999usd
Payment Terms :
T/T
Supply Ability :
1,000 units per month
Delivery Time :
3~7day
Packaging Details :
wooden box
Name :
CO2 laser cutting machine
Model :
1300x900mm
Laser Source :
CO2 Laser Tube
Laser Power :
130W/150W/180W/200W/300W/450W
Positioning Accuracy :
0.02mm
Repet.Positioning Accuracy :
0.01mm
Max.Cutting Thickness :
30mm (acrylic,plywood,rubber,MDF)
Power supply :
220V,50/60Hz
File format :
DXF, PLT, AI, DST, DSB
Net Weight :
500kgs
Application Materials :
Fabric,Leather,Acrylic,Paper,Wood,Bamboo,Ceramic, Rubber,Sponge,Plastic,etc.
Dimensions :
1750x1650x1150 mm
Description
T9-L1390 300W Wood board CO2 laser cutting machine Bamboo board cutting Composite panel cutting

Product Description:

The 1390 Co2 Laser Cutting Machine is a high-quality CNC Co2 laser cutting machine designed for precision cutting and engraving tasks. With a generous working area of 1300mm*900mm, this machine offers ample space to work on a variety of materials with ease and efficiency.

One of the standout features of this CNC Co2 laser cutting machine is its exceptional positioning accuracy of ±0.01mm, ensuring that every cut is precise and consistent. Whether you are working on intricate designs or large-scale projects, this machine delivers reliable results every time.

300Watt Wood Board 1390 Co2 Laser Cutting Machine Screw Type T9-L1390300Watt Wood Board 1390 Co2 Laser Cutting Machine Screw Type T9-L1390300Watt Wood Board 1390 Co2 Laser Cutting Machine Screw Type T9-L1390300Watt Wood Board 1390 Co2 Laser Cutting Machine Screw Type T9-L1390
300Watt Wood Board 1390 Co2 Laser Cutting Machine Screw Type T9-L1390
Cutting Accuracy

Our laser cutting machine integrates high-precision PMI lead screw guides and Japanese Mitsubishi servo motor drive system to ensure stable accuracy during continuous operation.

Cutting Thickness Parameters
Material Thickness Processing Speed (mm/s) Processing Power
1mm 60-70 35-40
3mm 50-60 50-60
5mm 35-40 60-65
8mm 17-23 60-65
10mm 12-17 60-65
12mm 10-14 65-70
15mm 6-8 65-70
20mm 2.5-4 65-70
30mm 1.4-1.8 65-70

Note: The above parameters are for reference only. The cutting effect may vary based on material quality. Please adjust power and speed according to actual conditions.

Configuration and Parameters
300Watt Wood Board 1390 Co2 Laser Cutting Machine Screw Type T9-L1390
Exhibition and Inspection
300Watt Wood Board 1390 Co2 Laser Cutting Machine Screw Type T9-L1390
Packaging and Logistics
300Watt Wood Board 1390 Co2 Laser Cutting Machine Screw Type T9-L1390
