Specifications
Brand Name :
YUHONG
Model Number :
TEMA BEU TYPE
Certification :
API 660, ASME U Stamp, CRS, NB Certificated, GB/T 151
Place of Origin :
China
MOQ :
1Set
Price :
10,000-500,000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10SETS/MONTHS
Delivery Time :
100-120DAYS
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Code :
ASME VIII DIV.1, TEMA CLASS "R", GB/T 151
Tube :
SA249 TP304, U BEND TUBE
Tube size :
O.D. 31.75 X 1.65 THK.
Channel :
ASME SA516 GR.70
Baffle :
SS400
Tubesheet :
SA266 GR.2
Description

TEMA Certified Heat Exchanger: SA249 TP304 Welded Tubes for Flue Gas Scrubbers

YUHONG specialize in the design and manufacturing of pressure vessels and heat exchangers, holding ​​ASME U Stamp​​ and ​​TEMA certifications​​. Our production strictly adheres to ​​ASME Section VIII, Division 1​​ and ​​TEMA standards​​, delivering high-performance equipment for industries including petrochemicals, chemicals, power generation, pharmaceuticals, and environmental protection.

SA249 TP304 Welded Tubes: Material Overview

Property​​

​​Description​​
​​Chemical Composition​​ - Chromium (Cr): 18.0–20.0%
- Nickel (Ni): 8.0–11.0%
- Carbon (C): ≤0.08%
- Manganese (Mn): ≤2.00%
- Silicon (Si): ≤1.00%
​​Mechanical Properties​​ - Tensile Strength: ≥515 MPa
- Yield Strength: ≥205 MPa
- Elongation: ≥35%
- Hardness: ≤92 HRB
​​Corrosion Resistance​​ Excellent in humid/oxidizing environments;
​​Weldability​​ Superior weldability;
​​Thermal Conductivity​​ For heat transfer requirements.

Cost Advantages of SA249 TP304 Welded Tubes

​​Advantage​​
​​1. High Material Utilization​​
​​2. High Production Efficiency​​
​​3. Lower Equipment Investment​​
​​4. Stable Pricing​​
​​5. Scalability​​

SA249 TP304 Welded Tubes vs. SA213 TP304 Seamless Tubes

​​Parameter​​

​​SA249 TP304 Welded Tubes​​

​​SA213 TP304 Seamless Tubes​​
​​Material Cost​​ Lower (thin-plate welding, minimal waste). Higher
​​Pressure Tolerance​​ low-to-medium pressure For high-pressure/temperature (e.g., boilers).
​​Corrosion Resistance​​ acidic/oxidizing environments. acidic/oxidizing environments.
​​Economy​​ Cost-effective for large projects. Higher cost.
​​Weld Quality​​ ERW/TIG avoids weld-related risks.
​​Applications​​ FGD systems extreme conditions.

TEMA Certified Heat Exchanger: SA249 TP304 Welded Tubes for Flue Gas Scrubbers
