Specifications
Supply Ability :
1000 TONS / month
Material Grade :
UNS R50400 / Grade 2
Model Number :
ASME SB338 UNS R50400 Grade 2 Titanium SMLS Tube
Product Type :
Seamless Heat Exchanger Tube
MOQ :
500 KGS
Delivery Time :
Depends on order quantity
Payment Terms :
T/T, L/C AT SIGHT
Size Range :
Custom OD, WT & U-Bend Radius Available
Price :
Negotiable
Product Form :
Seamless Tube
Certification :
ISO 9001/TUV/PED
Standard :
ASME SB338
Brand Name :
YUHONG
Lengths :
Custom cut or standard lengths
Place of Origin :
China
Packaging Details :
Steel frame wooden case with plastic cap
Description

ASME SB338 UNS R50400 Grade 2 Titanium SMLS Tube For Industrial Applications

Product Introduction

ASME SB338 UNS R50400 Grade 2 Titanium Tube Overview

ASME SB338 UNS R50400 Grade 2 titanium tube is a commercially pure titanium tube manufactured according to ASME SB338 specification for heat exchanger and industrial applications.

Grade 2 titanium is one of the most widely used commercially pure titanium grades due to its combination of corrosion resistance, low density and suitable mechanical properties.

These titanium tubes are commonly used in environments requiring resistance against seawater, chloride-containing media and chemical processing conditions.

The tubes can be supplied in seamless or welded forms with customized dimensions according to engineering requirements.

Technical Specifications

Specification of UNS R50400 Grade 2 Titanium Tube

Item Specification
Product Name Grade 2 Titanium Tube
Material Grade UNS R50400
Standard ASME SB338
Material Type Commercially Pure Titanium
Grade Titanium Grade 2
Manufacturing Type Seamless / Welded
Outer Diameter Customized
Wall Thickness Customized
Length Random Length / Fixed Length
Surface Treatment Pickled / Bright Finish / Customized
Heat Treatment According to specification requirements
Inspection Dimensional Inspection, Mechanical Testing, NDT
Certification Material Test Certificate (MTC)

Chemical Composition

Chemical Composition of Titanium Grade 2

Element Requirement
Titanium (Ti) Balance
Carbon (C) ≤0.10%
Oxygen (O) ≤0.25%
Nitrogen (N) ≤0.03%
Hydrogen (H) ≤0.015%
Iron (Fe) ≤0.30%

Mechanical Properties

Mechanical Properties of UNS R50400 Titanium Tube

Property Requirement
Tensile Strength ≥345 MPa
Yield Strength ≥275 MPa
Elongation ≥20%
Density Approx. 4.51 g/cm³

Applications

Applications of ASME SB338 Grade 2 Titanium Tube

Heat Exchanger Industry

Commonly used in:

  • Shell and tube heat exchangers
  • Condenser tubes
  • Cooling systems

Chemical Processing Equipment

Applications include:

  • Chemical reactors
  • Process piping
  • Corrosive media transportation systems

Marine Engineering

Used for:

  • Seawater cooling systems
  • Offshore equipment
  • Marine heat exchangers

Power Generation

Applications:

  • Condenser systems
  • Cooling water systems

Desalination Equipment

Titanium tubes are commonly selected for:

  • Seawater desalination plants
  • Reverse osmosis supporting equipment

Product Advantages

Advantages of ASME SB338 UNS R50400 Titanium Tube

Compliance with ASME SB338 Standard

Manufactured according to ASME SB338 requirements for seamless and welded titanium alloy tubes.

Excellent Corrosion Resistance

Grade 2 titanium provides corrosion resistance characteristics suitable for seawater and chemical processing environments.

Wide Application Range

Suitable for:

  • Heat exchangers
  • Chemical equipment
  • Marine systems
  • Industrial cooling systems

Traceable Material Documentation

Available documents include:

  • Material Test Certificate
  • Chemical Composition Report
  • Mechanical Test Report
  • Inspection Records

Difference Between Titanium Grade 2 and Grade 5

Item Grade 2 Grade 5
Material Type Commercially Pure Titanium Titanium Alloy
Strength Moderate Higher
Corrosion Resistance Excellent Good
Typical Use Heat exchangers, chemical equipment Aerospace, structural parts
