Data Center In-Row Cooling System L50 High Precision Air Conditioner for Server Rooms
Data Center In-Row Cooling System L50 High Precision Air Conditioner for Server Rooms
Data Center In-Row Cooling System L50 High Precision Air Conditioner for Server Rooms
Data Center In-Row Cooling System L50 High Precision Air Conditioner for Server Rooms
Data Center In-Row Cooling System L50 High Precision Air Conditioner for Server Rooms
Data Center In-Row Cooling System L50 High Precision Air Conditioner for Server Rooms
Data Center In-Row Cooling System L50 High Precision Air Conditioner for Server Rooms
Data Center In-Row Cooling System L50 High Precision Air Conditioner for Server Rooms
Specifications
Brand Name :
Hailos
Model Number :
L50
Place of Origin :
China
MOQ :
1pcs
Price :
Inquiry
Payment Terms :
T/T
Delivery Time :
6-8 weeks
Packaging Details :
Wooden cartons
Model :
L50
Cooling capacity :
53.5
Fan type :
EC centrifugation
air volume m³/h :
13000
refrigerant :
R410a
Unit size :
600*1200*2000
Weight Kg :
550
Power Supply Specifications :
380V 3Ph -50Hz
Description

Data Center In-Row Cooling System L50 High Precision Air Conditioner for Server Rooms

Energy Efficient

Close to the heat source, high cooling efficiency, reducing local hot spots Full sensible heat design, matching the load of the computer room

The high-efficiency EC fan cooperates with the EC compressor/water valve, and the optimized design of the cooling capacity stepless adjustment structure reduces wind resistance, power and noise

High Reliability

24 hours × 365 days continuous uninterrupted operation, the design life of 10 years All accessories have been strictly inspected and

tested, and the performance is stable. PTC heater is used, which is safe and reliable

Application

Modular Data Center

High Thermal Density Data Center

Container Data Center

Specification

Model LXXAW L35 L40 L50 L60

Cooling

capacity

 Capacity KW 38.2 45.5 53.5 60.1
Sensible cooling capacity KW 38.2 45.5 53.5 60.1
Sensible heat ratio 1 1 1 1
compressor Variable frequency vortex compressor
Fan Fan type EC centrifugation
air volume m³/h 8200 12000 13000 14000
Air supply method The rear return air supply is equipped with a front air supply panel and can be configured with an adjustable directional air guide plate to achieve various modes such as front horizontal air supply, left side horizontal air supply, right side horizontal air supply, and horizontal air supply from both sides.
Expansion valve Electronic expansion valve
refrigerant R410a
Optional Heating amount KW 6 6 6 6
Humidification Kg/h 3 3 3 3
Unit size Width mm 600 600 600 600
Depth mm 1200 1200 1200 1200
Height mm 2000 2000 2000 2000
Connecting pipes Gas pipe mm Φ22 Φ22 Φ28 Φ28
Liquid pipe mm Φ16 Φ16 Φ22 Φ22
Drain pipe mm Φ19 Φ19 Φ19 Φ19
Humidifier inlet pipe G1/2” G1/2” G1/2” G1/2”
Weight Kg 390 420 550 680
Power Distribution Parameters Power Supply Specifications 380V 3Ph -50Hz
Recommended Circuit Breaker D63 D63 D80 D80
Wiring Specifications mm² 10 10 16 16
Outdoor unit Outdoor unit model L35W L40W L50W L60W
Quantity of outdoor units 1 1 1 1
Weight Kg 85 130 130 160
Wiring specifications mm² 2.5 2.5 2.5 2.5
Vertical installation Width mm 850 1470 1470 2100
Depth mm 550 550 850 1100
Height mm 1600 1085 1085 1085
