Specifications
Model Number :
MK-710WS
MOQ :
1
Price :
Inquiry
Payment Terms :
T/T
Supply Ability :
500 sets per month
Delivery Time :
5-8 weeks
Packaging Details :
wooden cartons
Model :
MK-710WS
Cooling Capacity :
749.9
Power supply :
3N-380V/50Hz
Compressor Rated power :
154.0
Rated current/A :
267.3
Refrigerant :
160.0
Amount of water M3/h :
155.5
weight :
3200
Description

Description

The waterrcooled screw chiler is an efficent and stable industrial relrigeration equioment that adopts advanced screwcompression technology and high-efficiency shell and tube condenser, designed specilically for industrial environmentsthat require large cooling capacily and continuous cooling. It has high refrigeration efficiency, stable aperation, energyconservation and environmental protection, and is widely used in industries such as central air conditioning systems,chemicals, food and beverage, pharmacoutical manutacturing, clectronics, etc., providing customers with relablerefrigeration solutions.

Specification

型号 Model

MK-710WS

MK-830WS

MK-930WS

MK-410WD

MK-510WD

MK-620WD

MK-710WD

参数 Parameter

额定制冷量
Designed capacity

KW/h

50HZ

749.9

878.5

991.1

815.8

1035.4

1287.8

1499.8

X1000Kcal

644.9

755.5

852.3

701.6

890.4

1107.5

1289.8

温度范围
Temperature range

5℃-15℃/25℃-30℃

电源
Power supply

3N-380V/50Hz

压缩机
Compressor

类型
Type

半封闭螺杆式 Semi-hermetic screw

数量
Quantity

1

1

1

2

2

2

2

额定功率 KW
Rated power

154.0

181.4

204.9

175.0

214.4

270.0

308.0

额定电流 A
Rated current/A

267.3

317.4

357.7

308.8

370.0

465.6

534.6

能效调节
Energy saving

0.25%-50%,75%-100%

制冷剂
Refrigerant

种类
Type

R22

充注量KG
充注量KG

160.0

184.0

208.0

96*2

120*2

144*2

160*2

节流方式
Throttle method

外平衡式能力蒸发器 Thermal expansion valve

冷凝器
Condenser

形式
Form

壳管式冷凝器 Shell and tube condenser

水量 M3/h
Amount of water M3/h

155.5

182.3

205.7

170.4

215.0

267.9

310.9

进出水规格
Inlet and outlet water size

DN150

DN150

DN200

DN150

DN200

DN200

DN200

蒸发器
Evaporator

形式
Form

壳管式蒸发器 Shell and-tube evaporator

水量 M3/h
Amount of water M3/h

129.0

151.1

170.5

148.3

178.1

221.5

258.0

进出水规格
Inlet and outlet water size

DN150

DN150

DN200

DN150

DN200

DN200

DN200

机器尺寸
Machine size

L/mm

3600

3600

3600

3200

3400

3600

3600

W/mm

1600

1600

1600

1700

1700

1700

1800

H/mm

1700

1700

1700

1850

1850

1850

1800

机组重量
Unit weight

KG

3200

3450

3700

3500

4000

4500

5000
