Model | XZS5552THBZ | ||
Pumping system | Max. Theor. output | m3/h | 180 |
Max. Theor. concrete output Pressure | MPa | 13 | |
Rated working pressure | MPa | 35 | |
Pumping frequency | min-1 | v27/17 | |
Hopper capacity | L | 650 | |
Filling height |
| 1540 | |
Hydraulic system type |
| Open loop | |
Distribution valve |
| S valve | |
Oil cylinder dia.×stroke | mm | Φ230×2100 | |
Concrete cylinder dia.×stroke | mm | Φ230×2100 | |
Hydraulic oil cooling |
| Air cooling | |
Recommended concrete slump | cm | 12~23 | |
Max. aggregate dimension | mm | 40 | |
Placing boom | Structure type |
| 62-6RZ |
Placing depth | m | 55.9 | |
Horizontal distance | m | 62 | |
Placing depth | m | 56 | |
Slewing angle |
| ±270° | |
Boom number |
| 5 | |
The length of boom section | mm | 8890/8100/8105/5405/3500 | |
Sections folding angle |
| 90°/180°/180°/250°/90° | |
Pipe diameter | mm | 125 | |
End hose length | mm | 3000 | |
Min. height of opening placing boom | mm | 9610 | |
Outriggers span (front×rear×side) | mm | 8190×8345×7045 |
1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
