Specification Details | Values |
Vehicle Parameters |
|
- Overall Length | 9185 mm |
- Overall Width | 2470 mm |
- Overall Height | 3040 mm |
- Wheelbase | 4700 mm |
- Loading Height | 1500mm |
- Vehicle Weight (Approximate) | 12,000 kg |
Pumping System |
|
- Theoretical Concrete Pressure | 18MPa 8.7MPa |
- Theoretical Concrete Output | 90 m³/h 54 m³/h |
- Delivery Cylinder (Dia.×Stroke) | Φ200 × 1,600 mm |
- Hopper / Hydraulic Tank | 0.6 m³ / 700 L |
Engine Rated Power | 181/186 kW |
Chassis & Engine |
|
- Chassis Brand & Model | Dongfeng Tianjin DFL1120B |
- Engine Model | ISDe180 30 |
- Engine Power | 132 kW |
- Engine Displacement | 4.5 L |
- Emission Standard | China III (GB3) |
- Transmission Type | (Not Specified) |
- Fuel Tank Capacity | 300 L |
- Maximum Speed | 90 km/h |
Why Choose the SY5125THB-9018III?
1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
