Specifications
Brand Name :
XCMG
Model Number :
Isuzu Hb37
Certification :
ISO9001: 2000, CE
Place of Origin :
China
MOQ :
1
Price :
US$70,000.00 - 120,000.00
Payment Terms :
T/T
Supply Ability :
500pieces/Year
Packaging Details :
Bulk Cargo Shipping
Description

Product Description

No. Item Unit Parameter
1 Max. speed km 90
2 Min. turning diameter m 18.4
3 Brake distance m 7
4 Approach angle ° 31
5 Departure angle ° 12
6 Chassis model
CXZ51Q ( Japan )
7 Total weight kg 28150
8 1st axle load kg 6780
9 2nd, 3rd axle load kg 21220
10 Engine model
6WF1
11 Max. Engine power kW 287
12 Max. Engine torque N.m 1862
13 Max. grade-ability % 38
14 Fuel consumption limit L/100km 34
15 Outline dimensions (Length´ Width ´Height) mm 11990´2490´3900



Technical Data for Pumping Operation


No. Item Unit Parameter
1 Theoretical output m3/h 138/90
2 Max. delivery pressure MPa 8.7/13
3 Reach height m 37.4
4 Reach depth m 23.7
5 Front outrigger transverse span mm 7280
6 Rear outrigger transverse span mm 6600
7 Outrigger longitudinal span mm 6860
8 Delivery pipe diameter mm 125
9 Remote control distance m 100
10 Placing boom slewing range ° 370






Company Profile

Hb37 Used Concrete Pump for Large-scale Construction Projects


Hb37 Used Concrete Pump for Large-scale Construction Projects

FAQ

1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .

2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.

3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.

4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.

5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
