SANY STC250T4 25-Ton Truck Crane (2019) – Used | Excellent Condition

Overview:
This 2019 SANY STC250T4 is a robust and versatile 25-ton class truck crane designed for high performance in construction, infrastructure, and utility projects. Featuring a 35-meter main boom, with jibs, and Euro 5 emission compliance, this crane combines power, reach, and eco-friendliness. The unit is in original paint with no accidents, ensuring reliability and longevity.

Key Specifications:

1. Lifting Capacity:

   • Max. Rated Capacity: 25 tons

   • Max. Load Moment: 980 kN·m

2. Boom System:

   • Main Boom Length: 35 meters (5-section, U-shaped telescopic boom)

   • Jibs: Optional offset fly jib (e.g., 7.5–9.5m, enhancing max. tip height to ~45m)

   • Boom Extension: Hydraulic telescoping with precision control

3. Engine & Performance:

   • Engine Model: Cummins ISDe180 50 (Euro 5 compliant)

   • Engine Power: 180 HP (132 kW) @ 2,200 rpm

   • Emission Standard: GB5

   • Max. Travel Speed: 80 km/h

   • Gradeability: 45%

4. Chassis & Axles:

   • Chassis Configuration: 4×2 or 6×4 (depending on region)

   • Suspension: Hydraulic + leaf spring

   • Tires: 12.00R20 (heavy-duty radial tires)

5. Operational Features:

   • Hydraulic System: Load-sensing LUDV system for smooth operation

   • Control: Joystick + CAN-bus intelligent control

   • Safety: Moment limiter, overload warning, boom angle sensor

6. Dimensions:

   • Transport Length: ~12.5m

   • Transport Width: ~2.5m

   • Transport Height: ~3.4m

   • Gross Weight: ~32 tons

7. Additional Features:

   • Cab: Spacious, ergonomic, with air conditioning

   • Outriggers: H-type, 5.6m span (front/rear)

   • Certification: CE, ISO-compliant

Condition & Advantages:

• Well-maintained, original paint with no structural repairs.

• Low working hours (specific hours available upon request).

• Ideal for medium-duty lifting, urban projects, and logistics.
