High-end Surface Spraying Machines with Universal Spray Gun Series & Professional Paint System Equipment
W-71 Universalspray gun series
Function and characteristics
W-71 nozzle and thimble are heat-treated materials, high hardneess, wear resistance and durability.
W-71 nozzle can be removed and cleaned, the atomization is even and delicate,and the spray width is wide.
W-71 is suitable for surface painting of furniture, automobiles, plastics, home appliances, etc., covering most of the
spraying industry, cost-effective, and the public chooses.
Model |
Nozzle diameter
Φ mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Spraying width
mm | Weight |
| W-71-PO8 | 0.8 | 0.34(3.5) | 200 | 240 | 200 | 455 |
| W-71-P10 | 1.0 | 300 | 230 | 275 |
| W-71-G/S10 | 1.0 |
| 110 | 75 | 130 |
| W-71-G/S13 | 1.3 | 0.29(3.0) | 160 | 195 | 175 |
| W-71-G/S15 | 1.5 | 190 | 230 | 195 |
| W-71-G/S18 | 1.8 |
| 220 | 230 | 230 |
W-71's surface coating type: P stands for pressure feed type, G stands for gravity feed type, S stands for siphon feed type. The spraying distance of W-71 is 200mm, the coating viscosity is 20±10 seconds/NK-2, and the coating pressure of the pressure feed type is 0.8kg/cm².
W77 Universalspraygun series
Function and characteristics
W-77large diameter design, suitable for medium viscositly coating, nozzle and thimble for heat treatment material.
high hardness, wear resistance and durability.
W-77 nozzle atomizing cap can be removed and cleaned, the atomizirig cap is processed with high precision, the
atomization is even and delicate, and the spray width is wide.
W-77 is suitable for surface painting of furniture,automobiles, plastiecs, home appliances. etc.
| Model | Nozzle Diameter
φmm | Spray Air PressureMpa(kgf/cm²) | Coating output
ML/min | L/min |
Spraying width
mm | Weight |
| W-77-P12 | 1.2 | 0.34(3.5) | 480 | 430 | 390 | 530 |
| W-77-G/S15 | 1.5 | 0.34(3.5) | 270 | 290 | 300 |
| W-77-G/S20 | 2.0 | 440 | 360 | 330 |
| W-77-G/S25 | 2.5 | 520 | 460 | 340 |
| W-77-G/S30 | 3.0 | 550 | 460 | 360 |
The expression form of W-77: P represents pressure feeding type, G represents gravity type, and S represents suction type. The spraying distance of W-77 is 250mm, the coating viscosity is 20±1 seconds/NK-2, and the coating pressure of the pressure feeding type is 0.8kg/cm².
W-101 Universalspraygun series
Function and characteristics
W-101 lightweight design, the trigger pull is soft, flexible, and the gripgood
The paint channels are made of stainless steel. The nozzles and thimbless are made of high-grade stainless steel.
They have high hardness and wear resistance, which can prolongthe service life.
Scope of application: suitable for spray paint, paint, epoxy resin, glue, d other spray liquids. It is mainly
used for automobile repair, furniture, home appliances, metal spraying,etc.,and the scope of application is wider.
| Model |
Nozzle Diameter
Φ mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Spraying width
mm |
Weight
G |
| W-101-P08 | 0.8 | 0.29(3.0) | 150 | 270 | 190 | 315 |
| W-101-P10 | 1.0 | 200 | 220 | 220 |
| W-101-P13 | 1.3 | 0.24(2.5) | 200 | 200 | 230 |
| W-101-P15 | 1.5 | 250 | 220 | 240 |
| W-101-G/S10 | 1.0 | 0.24(2.5) | 95 | 75 | 130 |
| W-101-G/S13 | 1.3 | 160 | 145 | 170 |
| W-101-G/S15 | 1.5 | 190 | 225 | 180 |
| W-101-G/S18 | 1.8 | 230 | 170 | 190 |
For W-101: In its expression form, P stands for pressure-fed type, G stands for gravity-fed type, and S stands for suction-fed type. For VV-101, the spraying distance is 200mm, the coating viscosity is 20±1 second/NK-2, and for the pressure-fed type, the coating pressure is 0.8kg/cm²
W-101R Pill blowing gun series
Model |
Nozzle Diameter
Φ m m |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Spraying width
mm |
Weight
G |
| W-101-RO5 | 0.5 | 0.29(3.0) | 120 | 270 | 40 | 320 |
| W-101-R08 | 0.8 | 150 | 60 |
| W-101-R10 | 1.0 | 200 | 75 |
| W-101-R13 | 1.3 | 0.24(2.5) | 200 | 220 | 90 |
| W-101-R15 | 1.5 | 250 | 105 |
| W-101-R18 | 1.8 |
| 240 | 150 | 95 |
|
For W-101R: In its expression form, R stands for spray gun with a tip guard. The spraying distance is 200mm, the coating viscosity is 20±1 second/NK-2, the coating pressure for the pressure-fed type is 0.8kg/cm², and the coating inlet and air inlet are 1/4PF/NPF.
W-101 Highatomizingspray gun series
Function and characteristics
It adopts white iron nozzle,which is not easy to deform,highprecision machining and high concentricity.
The oil quantity is fast, the spraying efficiency is greatly improoved, the atomization is fine and uniform, the effect is excellent, the spraying efficiency is high,andthespeedisfast.
Mainly used for automotive repair, furniture,home appliances, rmetal and other spraying, the scope of application is more extensive.
| Model |
Nozzle Diameter
Φ mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min | L/min |
Weight
G |
| W-101-PO8 | 0.8 | 2.5-3.0(0.24-0.29) | 170 | 270 | 325 |
| W-101-P10 | 1.0 | 220 | 220 |
| W-101-P13 | 1.3 | 220 | 200 |
| W-101-P15 | 1.5 | 270 | 220 |
| W-101-P18 | 1.8 | 250 | 170 |
LD-W101 Sprinkle spray gun series
Function and characteristics
The atomization effect can be sprayed with fine dots and thick dots.
Model |
Coating supply
method |
Nozzle Diameter
Φ mm |
Coating output
ML/min |
L/min |
pray Air Pressur
Mpa(kgf/cm²) |
Weight
G |
| LD-W101 | Pressure feed | 0.8 | 150 | 80 | 0.2(2.0) | 295 |
LD-71 Chaos spray gun series
Function and characteristics
It can spray a pattern of loose, thin,fine dots.
The three kinds of gun caps can be freely replaced and sprayed withdifferent chaotic patterns.
Model |
Coating supply
method |
Nozzle Diameter
Φ mm |
Coating output
ML/min |
L/min |
Spray Air
Pressure
Mpa(kgf/cm²) |
Weight
G |
| LD-71 |
Pressure feed | 0.7 | 80 | 80 | 1.0-2.5
(0.1-0.25) | 1012 |
| 2 | 140 | 140 |
R2 Repair spraygun series (round)
Function and characteristics
The nozzle and thimble are made of high-grade stainless steel and are suitable for spraying water-based paints.
Suitable for spraying on smallhardware,plastic molds,art crafts,woodwork,leather,toys,automobiles,etc.
Model |
Nozzle Diameter
Φ mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min | Spraying width
mm | Weight
G |
| R2-R | 0.5 | 1.8-2.5
(0.18-0.24) | 20 | 35 | totally blown over | 245 |
| R2-R | 0.8 | 40 | 45 |
R2 Repair spraygunseries (sector)
Function and characteristics
·The nozzle and thimble are made of high-grade stainless steel and are suitable for
·spraying waterborne coatings.
·The nozzle can be removed and cleaned,and the atomization is even and delicate.
Suitable for spraying on small hardware,plastic molds,art crafts,woodwork,leather,toys,automobiles,etc.
Model |
Nozzle Diameter
Φ mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coatingoutput
ML/min |
L/min |
Spraying width
mm |
Weight
G |
| R2 | 0.3 | 1.8-2.5
(0.18-0.24) | 6 | 30 | 50 | 260 |
| R2 | 0.5 | 20 | 35 | 50 |
| R2 | 0.8 | 60 | 40 | 80 |
| R2 | 1.0 | 80 | 45 | 100 |
LD-77 Polychrome spray gun series
Function and characteristics
·Water-in-water multi-color spraying gun for spraying construction of inner and outer walls of spraying plant
·Suitable for metal paint,multi-color paint,stone paint,granite paint, fluorocarbon paint,etc.
Model |
Nozzle Diameter
Φ mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Weight
G |
| LD-77 | 1.5 | 0.3(3.0) | 400 | 560 | 530 |
| 2.0 | 440 | 560 |
| 2.5 | 480 | 560 |
| 3.0 | 520 | 560 |
LD-WA200 Polychrome spray gun series
Function and characteristics
·Water-in-water multi-color spraying gun for spraying construction of inner and outer walls of spraying plant
·Suitable for metal paint,multi-color paint,stone paint,granite paint, fluorocarbon paint,etc.
Model |
Nozzle Diameter
Φ mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Weight
G |
| 2.5 |
| 480 | 450 |
|
| LD-WA200 | 3.0 | 0.3(3.0) | 520 | 550 | 500 |
LD-1 Release agent spray gun series
Function and characteristics
·Suitable for water and oil release agent spray,water transfer activator spray.
·Small size,light weight,easy to use and easy to operate.
Model |
Nozzle Diameter
Φ mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coatingoutput
ML/min |
L/min |
Spraying width
mm |
Weight
G |
| LD-1 | 0.3 | 2.0(0.2) |
Pressure feed | 35 | 5 | 255 |
| 0.5 | 40 | 20 |
| 0.8 | 45 | 40 |
Gesture pen gun
Function and characteristics
·Small size,easy to operate,suitable for
·line surface spraying.
Suitable for automotive scratch repair,beauty and crafts industries.
WA-101/200 Automatic spray gun series
Function and characteristics
·The traditional gun body design,the paint channel is made of stainless steel,the nozzle and thimble are made of high-grade stainless steel,high hardness,wear resistance and durability.
·Applicable coating range is wide,suitable for combination of production line,automatic spraying machine, reciprocating spraying machine and painting robot.
·Applicable to pharmaceutical coatings,glass,furniture,home appliances,aviation,shipbuilding and other industries.
Model |
Nozzle Diameter
mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Spraying width
mm |
Weight
G |
| WA-101-PO8 | 0.8 | 0.29(2.9) | 150 | 270 | 190 | 440 |
| WA-101-P10 | 1.0 | 200 | 270 | 220 |
| WA-101-P13 | 1.3 | 250 | 260 | 230 |
| WA-101-P15 | 1.5 | 270 | 260 | 245 |
| WA-101-P18 | 1.8 | 310 | 190 | 240 |
| WA-200-P12 | 1.2 | 500 | 530 | 400 | 470 |
| WA-200-P15 | 1.5 | 270 | 330 | 340 |
| WA-200-P20 | 2.0 | 400 | 360 | 320 |
| WA-200-P25 | 2.5 | 500 | 360 | 330 |
| WA-200-P30 | 3.0 | 0.55(5.5) | 650 | 550 | 370 |
LD-WA101 Chaos spray gun series
Coating supply method:Pressure Feed
Paint nozzle caliber:0.8mm
Air usage:80 /min
Spray amount of paint:80ml/min
Weight:522g
WA-101R Series
Function and characteristics
·The traditional gun body design,the paint channel is made of stainless steel,the nozzle and thimble are made of high-grade stainless steel,high hardness,wear resistance and durability.
·Applicable coating range is wide,suitable for combination of production line,automatic spraying machine,reciprocating spraying machine andpainting robot.
Model |
Nozzle Diameter
φmm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Weight
G |
| WA-101-R05 | 0.5 | 0.29(3.0) | 60 | 40 | 440 |
| WA-101-R10 | 1.0 | 250 | 50 |
| WA-101-R13 | 1.3 | 360 | 55 |
LD-5 Simple automatic spray gun
Function and characteristics
·Small size,light weight,simple operation,suitable for medicine,food, textile,plasticrubber,printing,vacuum blister,steel plate cooling,steelplate lubrication and other industries.
·Available in a variety of nozzle sizes.The nozzle and thimble are made of high-grade stainless steel for waterborne coatings.
Model |
Nozzle Diameter
mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Spray Style |
L/min |
Spraying width
mm |
Weight
G |
| LD-5 | 0.5 | 0.3(3.0) | 扇形及圆形
Fan-shaped and
round shaped | 60 | 200 | 280 |
| 1.0 |
| 1.3 | 80 | 250 |
| 2.0 |
LD-6 Simple automatic spray gun
Function and characteristics
·Small size,light weight,simple operation,suitable for medicine,food, textile,plastic,rubber,printing,vacuum blister,steel plate cooling,steelplate lubrication and other industries.
·Available in a variety of nozzle sizes.The nozzle and thimble are made of high-grade stainless steel for waterborne coatings.
Model |
Nozzle Diameter
φmm |
Spray Air Pressure
Mpa(kgf/cm²) |
Spray Style |
L/min |
Spraying width
mm |
Weight
G |
| LD-6 | 0.5 | 0.3(3.0) | 扇形及圆形
Fan-shapedand
round shaped | 100 | 350 | 300 |
| 1.0 |
| 1.3 | 140 | 400 |
| 2.0 |
LD-100 Simple total spray gun series
Function and characteristics
The gun body is light,small in size and easy to operate.
Suitable for spraying water-based paint,nozzle and thimble are made of stainless steel.
Applicable to the pharmaceutical,food,textile,plastics andother industries.
Model |
Coating supply
method |
Nozzle Diameter
m m |
Coating output
ML/min |
L/min |
Spray Air Pressure
Mpa(kgf/cm²) |
Weight
G |
| LD100-P08 |
| 0.8 | 150 |
|
|
|
| LD100-P10 |
Pressure feed | 1.0 | 200 | 270 | 0.3(3.0) | 248 |
| LD100-P13 | 1.3 | 250 | 260 | 0.25(2.5) |
| LD100-P15 | 1.5 | 270 |
| LD100-P18 | 1.8 | 310 | 190 |
LD-101R Pillblowing automatic spray gun series
Function and characteristics
·Smallparts are sprayed to reduce the trouble of shielding and reduce the contamination of the fixture.
·Porous cover(air cover)specification cover,spray air independent control specification liquid recyclable specifications.
Model |
Nozzle Diameter
mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Spraying width
mm |
Weight
G |
| LD-101R-P05 | 0.5 | 0.26 | 130 | 350 | full-face blowing | 350 |
| LD-101R-P08 | 0.8 | 150 |
WRA-101/200 Robot reciprocating machine special automatic spray gun series
Function and characteristics
·Intake adjustment and spray width adjustmentpaint discharge volume adjustment,set outside themachine,remote control,independent control,reduce operational troubles,suitable for a largenumber of painting applications,can be installed onthe robot arm or automated coating machineequipment.
·Inlet pressure can be adjusted freely according to your needs(2.0-3.5bar),reducing paint reboundand saving paint.
·Applicable to computer casings,mobile phone casings,cosmetic casings,furniture,homeappliances,medicine,food,textile,glass,plastic,rubber,printing,building materials and hardware.
Model |
Nozzle Diameter
m m |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Spraying width
mm |
Weight
G |
| WRA-101 | 0.5 | 0.29(3.0) | 130 | 270 | 180 | 285 |
| 0.8 | 150 | 190 |
| 1.0 | 200 | 220 |
| 1.3 | 0.24(2.5) | 250 | 260 | 230 |
| 1.5 | 270 | 260 | 245 |
| 1.8 | 310 | 190 | 240 |
| WRA-200 | 1.2 | 0.29(3.0) | 530 | 530 | 400 | 320 |
| 1.5 | 330 | 330 | 340 |
| 1.8 | 330 | 330 | 340 |
| 2.0 | 360 | 360 | 320 |
LD-618 Low pressure environmental protection spray gun series
Function and characteristics
·Low pressure and high atomization spraying gun can reduce the spatter of paint and improve the adhesion rate ofpaint
·Compared with traditional air sprayinggun,it can save 20%-30%of paint and air consumption.
Coatings can be circulated in the gun body to prevent the deposition of coatings and not easy to plugthe gun.
·Double atomization adiustingknob can not onlv adiust thewidth of atomization,but also adiust the thickness of
atomization.The atomization effect is more delicate and uniform.
Model |
Nozzle Diameter
mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Spraying width
mm |
Weight
G |
| 0.8 |
| 120 | 260 | 280 |
|
| LD-618 | 1.1 | 2.0-3.0
(0.2-0.29) | 150 | 270 | 320 | 525 |
| 1.3 | 160 | 280 | 380 |
| 1.5 | 200 | 285 | 420 |
| 1.8 | 250 | 295 | 450 |
| 2.0 | 300 | 300 | 470 |
LD-5200 Low pressure environmental protection spray gun series
Function and characteristics
·Quick release split structure foreasy disassembly,no tools required for disassembly,no need to reposition.
·Low-pressure high-atomization spray gun can reduce paint splash and improve paint adhesion rate,saving 20%-
30%paint and air consumption compared with traditional airspray gun.
·Itis set outside the machine and can be operated remotely,independently controlled to reduce the trouble of
operation.It can be installed on the robot arm orautomatically coating the machine equipment.
Model |
Nozzl i meter |
Spray Air Pressure
Mpa(kgf/cm²) |
Coating output
ML/min |
L/min |
Spraying width
mm |
Weight
G |
| LD-5200 | 0.7 | 2.0-3.0
(0.2-0.29) | 400 | 280 | 210 | 389 |
| 1.1 | 400 | 220 |
| 1.4 | 500 | 230 |
LD-5800 Robotic robot special automatic spray gun series
Function and characteristics
·Quick release split structure foreasy disassembly and maintenance.
·The spray gun nozzles are made of high-grade stainlesssteel,high hardness,wear resistance and durability,which greatly prolongs the service life.
Model |
Nozzl i meter |
Coating supply
method |
Coating pipe size
mm |
L/min |
Spraying width
mm |
Weight
G |
| LD-5800 | 0.7 |
Pressure feed | 6x4 | 280 | 22 | 370 |
| 1.1 |
| 1.4 |
Inner wall angle long rod spray gun series
Function and characteristics
·Suitable forspraying the innerwall of the pipe,the inner wall of the bottle,and sprayingon the side.
·The spray cap connecting pipe and paint pipe are made of stainless steel,which are not bent,deformed,wear-resistant and corrosion
Model |
Nozzle Diameter
mm |
Spray Air Pressure
Mpa(kgf/cm²) |
Paint nozzle
diameter
φmm |
Tube length
mm |
Atomization
angle
o |
Weight
G |
| W0609 WA 0609 |
|
| 6 | 90 |
|
|
| W-0915 WA-0915 | (0.60.81.01.5) | 3.0(0.29) | 9 | 150 | 14-19 | 505-1100 |
| W-1218 WA-1218 | 3.0(0.29) | 12 | 180 |
| W-1230 WA-1230 | 12 | 300 |
| W-1250 WA-1250 | 12 | 500 |
Industry Application
Package Detail
FAQ About Robot
1.Question: [SAFETY] I want to ensure the industrial robot I purchase complies with industry standards and regulations. What certifications does it have?
Answer: This industrial robot has passed strict industry certifications and standards, including ISO quality management system certification and CE certification and ATEX for painting robots, ensuring its quality and safety.
2.Question:[Technical support] I need an industrial robot with reliable technical support and training services. Do you offer support in this area?
Answer: Yes, we provide comprehensive technical support and training services, including operation training, maintenance training, and on-site support to ensure you can fully utilize the performance and capabilities of the industrial robot.
3.Question:[Material download ]Where can I obtain relevant information about robots, including parameter manuals, mathematical models, and so on
Answer: https://www.efort.com.cn/en/index.php/service/downservice.html
4.Question:【Warranty】how about your warranty
Answer :Yes, our products come with a certain period of warranty. The specific warranty period and coverage may vary depending on the product model and region. Please provide your location and the product model you are interested in to obtain more accurate information. In general, the warranty period is 12 months.
5.Question:【Payment】how about the payment if we place orders to you .
Answer :We accept multiple payment methods, including but not limited to TT, L/C, etc. You can choose the payment method that is convenient for you.
6.Question:[Customization] Do you provide any possible customized service .
Answer: Yes, we provide customization services within a certain range, such as color customization, boot UI customization, LOLO customization, etc., according to the specific requirements of customers. Please provide your customization requirements, and we will do our best to meet your needs.
7.Question: [maintenance] What are the maintenance costs for the industrial robot? I want to understand the long-term operating costs.
Answer: The maintenance costs for this industrial robot are very low. We provide maintenance services including regular inspections, preventive maintenance, and quick-response technical support to minimize your operating costs.
8.Question: [Easy to use ] I expect efficient programming capabilities in the industrial robot for quick deployment and adjustments on the production line. Does it offer efficient programming?
Answer: This industrial robot comes with user-friendly programming interfaces and advanced programming capabilities, allowing for quick and easy deployment and adjustments on the production line.
9.Question: [Reliability] How reliable is the industrial robot? I need a stable and dependable machine to ensure production continuity.
Answer: This industrial robot undergoes rigorous quality control and testing, ensuring excellent reliability and stability. It is built with advanced technology and high-quality materials to ensure continuous production.
Contact
Fengor_Hu (Mr)
Executive Director
MP:+86-15665538866 (whatsapp)
MP: +86-18356576525(wechat )
Skype: hufengguang1980
Email: hufengguang@techflyrobot.com
Anhui Techfly robotics technology Co., Ltd
www.techflyrobot.com
4th Floor,No.39 Wei Si Road,Jiujiang Economic Development Zone, Jiujiang District, Wuhu City, Anhui Province
