Fiber Optic Pigtail Single Mode B1 LC Adaptor
Fiber Optic Pigtail Single Mode B1 LC Adaptor
Fiber Optic Pigtail Single Mode B1 LC Adaptor
Fiber Optic Pigtail Single Mode B1 LC Adaptor
Specifications
Brand Name :
TC
Model Number :
FF-LC-B1-1M
Place of Origin :
China
Length :
Customized
Adaptor Type :
LC
Fiber Type :
Single Mode
Jacket material :
PVC/LSZH
Operating temperature :
-25~70 ℃
Standard :
IEC 60332-3C, IEC 60754-2, IEC 61034-2
Description

Fiber Optic Pigtail, Single Mode, FC Adaptor, PVC Sheath Applications


Optical fiber pigtail can be used in a variety of fiber termination applications, joint applications in splice trays of patch panels, together with FTTD applications.


Product Features


Pre-termination and testing in factories to ensure its transmission performance:

  • Yellow singlemode pigtail, orange multimode pigtail;
  • Fast network configuration to speed up installation;
  • Fire rating and flame resistance in accordance with IEC 60332-3C;
  • Non corrosive gas emission in accordance with IEC 60754-2;
  • Low smoke zero halogen emission in accordance with IEC 61034-2;
  • Insertion Loss ＜ 0.3dB;
  • Return Loss ＞ 50dB;
  • Custom tailored services for length, quantity of cores and physical structures.


Application Standards


YD/T 926.3, IEC 60332-3C, IEC 60754-2, IEC 61034-2

Technical Details

Optical Properties
Insertion Loss Interchangeability Return Loss
≤ 0.3dB ≤ 0.2dB APC singlemode ≥ 60dB PC singlemode ≥ 50dB PC multimode ≥ 35dB

Mechanical Properties
Quantity of Cores 1
Tensile Strength 150
Crush Resistance 15
Min. Bend Radius during
Installation (mm)		 20 Times the Optical Fiber Diameter
Min. Bend Radius during
Operation (mm)		 10 Times the Optical Fiber Diameter
Installation Temperature
Range (℃ )		 -5 to +50
Operation Temperature
Range (℃ )		 -20 to +60
Delivery and Storage
Temperature Range (℃ )		 -25 to +70
