Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
Specifications
Model Number :
P6.25
Pixel Pitch :
P6.25mm
Certification :
FCC, CE, ROHS
Cabinet Size :
W1600x H900mm
Brand Name :
TBC LED
Type :
Outdoor Football Stadium LED Perimeter
MOQ :
10sqm
Delivery Time :
25 days
Weight :
45kg
Warranty :
3 years
Payment Terms :
T/T
Max Power Consumption（W/㎡） :
600-800
Price :
Negotiable
Viewing Angle :
H160°/V160°
Supply Ability :
1000 sqm per month
Contrast Ratio :
5000: 1
Place of Origin :
China
Service :
Front&Rear Service
Packaging Details :
Flight Cases
Description
Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
Outdoor P10mm LED Perimeter Folding Aluminum Bracket 7000nits High Brightness 3840Hz Refresh Rate
Product Specifications
Parameter Specification
Model P6.25mm
LEDs 1R1G1B
LED Type SMD2727
Pixel Pitch 6.25mm
Unit Size W1600*H900mm
Unit Resolution 256*144 dots
Resolution 25,600 dots/㎡
Unit Direction Vertical Horizontal
Brightness 7000nit
Weight 45KG/Panel
Max Consumption 600-800W/㎡
Average Consumption 100-200W/㎡
Viewing Angle H160°/V160°
Protection Level IP65
Thickness 98mm
Heat Dissipation Convective heat dissipation
Power Supply Power supply with PFC
Installation Fast install
Service Front & Back
Control Mode Steady state
Color Temperature 3200-9300K
Refresh Rate 3840Hz
Working Temperature -40℃ to 70℃
Storage Temperature -55℃ to 120℃
Life Time ≥100,000 hours
Input Voltage AC90-264V
Grey Grade 16bit
Warranty 3 years
Key Advantages
  • Exceptional Outdoor Visibility
    Featuring 7000 nits ultra-high brightness and a 5000:1 contrast ratio, the display delivers brilliant colors and sharp images, remaining perfectly visible even under strong sunlight.
    Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
  • Lightweight Yet Durable Construction
    Built with a premium aluminum cabinet weighing just 45kg per panel, significantly reducing shipping costs and installation labor while maintaining outstanding structural strength.
  • Easy Maintenance, Maximum Uptime
    Designed with full front and rear maintenance, enabling fast module replacement and minimizing service time to keep your display running with maximum efficiency.
  • Enhanced Safety with Soft Protective Mask
    The durable polymer soft mask improves image contrast while providing superior impact protection, helping safeguard players during high-intensity sporting events.
    Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
  • Flexible Installation with Adjustable Brackets
    Equipped with adjustable folding brackets supporting multiple installation angles, ensuring the best viewing experience for every stadium layout.
    Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen Outdoor P6.25 LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance for Stadium Perimeter Sport LED Screen
Frequently Asked Questions
How does the service work?
We have experienced engineers with 15+ years in the industry who provide technical support via video conference, TeamViewer, or on-site guidance.
What installation options do we have?
Wall mounting with metal structures.
Do you have any MOQ limit for LED screen orders?
Low minimum order quantity - modules or complete screen orders are all welcome.
What's the shipping method?
Air freight, sea, and train transport available depending on region.
What's the payment method?
Telegraphic transfer - 50% before production and 50% balance before shipment.
How do you control the production quality?
Quality management from incoming materials, pre-inspected components, and 72+ hours aging tests for modules and complete screens.
How does warranty work?
1-3 years warranty with free repair or exchange of defective parts including one-way shipping.
