Specifications
Brand Name :
TBCLED
MOQ :
10sqm
Module Size :
500×250mm
Certification :
CE, RoHS, FCC, IP65
Gray Scale :
65536 levels per color
Panel Weight :
22.5Kg
Anti-glare Technology :
Matte surface coating, low reflection optical design
Price :
Negotiable
Supply Ability :
2000 sqm per month
Pixel Configuration :
SMD2727
Working Temperature :
-40℃ to 70℃
Lifetime :
≥100,000 hours
Model Number :
TB-T10-AG
Brightness :
≥6000nit
Power Consumption :
950W/sqm (Max), 330W/sqm (Average)
Payment Terms :
T/T,L/C,Western Union
Viewing Angle :
140°/140°
Panel Material :
Aluminum
Place of Origin :
Guangdong, China
Packaging Details :
Plywood box/Wooden case
Pixel Pitch :
P10mm
Panel Size :
1000×1000×83mm
Refresh Rate :
3840Hz
Protection Level :
IP65
Delivery Time :
15-25 working days
Description
Anti-glare Sunlight Readable T Series Outdoor LED Billboard P10 1000x1000mm 6000nit High Contrast Fixed Display
Product Overview

When your advertising message faces direct sunlight, standard LED displays wash out and lose impact. The Anti-glare Sunlight Readable T Series Outdoor LED Billboard solves this challenge with a combination of 6000nit ultra-high brightness, matte anti-glare surface coating, and optimized optical design that maintains crisp, readable content even under harsh midday sun.

Engineered for roadside billboards, building facades, and open-air commercial squares where sunlight exposure is unavoidable, this outdoor LED display delivers exceptional contrast and color accuracy that standard outdoor screens cannot match. The anti-glare technology reduces surface reflection by up to 65% compared to conventional outdoor LED panels, ensuring your advertising content remains clear and attention-grabbing from dawn to dusk.

Key Features
  • Anti-glare Matte Surface: Proprietary matte coating technology reduces sunlight reflection by 65%, eliminating the mirror-like glare that plagues standard outdoor LED displays. Content stays readable from all viewing angles regardless of sun position.
  • 6000nit Ultra-High Brightness: Daylight-visible brightness ensures vivid color reproduction and sharp text even under direct tropical sunlight. Automatic brightness adjustment maintains optimal visibility from sunrise to midnight.
  • High Contrast Optical Design: Specially engineered LED mask and louver design maximizes contrast ratio by blocking ambient light between pixels. Blacker blacks and brighter colors for superior visual impact.
  • Superior Heat Dissipation: Aluminum panel construction with integrated heat sink channels effectively dissipates heat from 6000nit operation, maintaining stable performance and extending LED lifespan.
  • IP65 Full Protection: Complete front and rear weather sealing against dust, rain, and humidity. Designed for year-round outdoor operation without additional protective enclosures.
  • Hot-Swap Maintenance: Hard link technology supports hot-swap module replacement, reducing maintenance downtime and service costs for roadside and elevated installations.
  • Seamless Multi-Panel Splicing: High-precision aluminum panels achieve seamless large-scale splicing for billboard-sized displays. Consistent brightness and color uniformity across the entire screen surface.
  • Wide Temperature Range: Reliable operation from -40℃ to 70℃, suitable for desert climates, tropical regions, and extreme winter conditions.
Performance Advantage

At midday, when pedestrian and vehicle traffic peaks, standard LED billboards can lose up to 40% of their effective visibility due to sunlight reflection. The anti-glare T Series maintains over 90% readability during peak sun hours—translating directly to higher advertising impressions and better ROI for outdoor media operators.

Technical Specifications
Pixel Pitch P10mm
Module Size 500*250mm
Panel Size 1000*1000*83mm
Refresh Rate 3840Hz
Brightness ≥6000nit
Pixel Configuration SMD2727
Gray Scale 65536 levels per color
Viewing Angle 140°/140°
Power Consumption 950W/sqm (Max), 330W/sqm (Average)
Protection Level IP65
Panel Material Aluminum
Panel Weight 22.5Kg
Working Temperature -40℃ to 70℃
Lifetime ≥100,000 hours
Anti-glare Matte coating, 65% reflection reduction

Anti-glare Matte Surface Outdoor LED Billboard with 6000nit Ultra-High Brightness and IP65 Full Protection

Anti-glare Matte Surface Outdoor LED Billboard with 6000nit Ultra-High Brightness and IP65 Full Protection

Anti-glare Matte Surface Outdoor LED Billboard with 6000nit Ultra-High Brightness and IP65 Full Protection

Typical Applications
Roadside Digital Billboards Building Facade Advertising Highway Information Displays Commercial Square Screens Rooftop Brand Signage Sports Stadium External Displays Transportation Hub Advertising Outdoor Retail Promotions
