Item

Descriptions

Specification

Machine Body

Table Width (mm)

2000

Rail length (mm)

4000

Effective Cutting Area(mm)

1500x3000

Drive motor

Dual-drive / Panasonic AC servo motor

Max traveling speed(mm/min)

9000mm/min

Flame Torch

Flame Cutting Torch Number

1 Set Flame torch

Flame Cutting Thickness(mm)

6-50mm

Flame Torch Height Sensor

Height sensor

Flame Cutting Speed(mm/min)

50-800mm/min

Flame cutting Gas Pressure

Oxygen:0.5-0.8MPa Flow:1.0M³/Min

Fuel Gas :Propane or Acetylene Pressure:0.05-0.1MPa

Plasma Torch

Plasma Cutting Torch Number

1 Set Plasma torch

Plasma Torch Height Sensor

TAYOR plasma arc Sensor THC

Plasma Torch Anti-Collision Holder

TAYOR

Plasma Cutting Speed(mm/min)

50-4500mm/min

Model

Hypertherm Powremax85

Plasma Cutting Thickness(mm)

1-15mm(carbon steel)

Country of origin

Made in USA

Max current output

85A

Power

15KW

Duty cycle

80%

Plasma Cutting Gas Request

Dry and Oil free compressed

CNC Controller

TAYOR

Nest Software

Nest Software

FASTCAM (Australia)

Electrical Components

PLC

DELTA TAIWAN

Electric Components

Schneider

Positioning Accuracy

±0.5mm/1000mm

Repeatability

±0.5mm/1000mm

Speed setting error

≤±5%

THC accuracy

≤±0.5mm

Length of a side Error(mm)

±0.5mm

Base Point Return Error

±0.4mm

Intersection point Error

±0.5mm

Lineation forward-reverse Error

±0.2mm
