Electricity car spray painting booth cabinets TG-80A
Electricity car spray painting booth cabinets TG-80A
Electricity car spray painting booth cabinets TG-80A
Electricity car spray painting booth cabinets TG-80A
Electricity car spray painting booth cabinets TG-80A
Electricity car spray painting booth cabinets TG-80A
Specifications
Brand Name :
TARGET
Model Number :
TG-80A
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1set
Price :
$6000---9000
Payment Terms :
T/T, L/C
Supply Ability :
1000set/month
Delivery Time :
5--7 days
Packaging Details :
Export standard package
Description

Electricity car spray painting booth cabinets TG-80AElectricity car spray painting booth cabinets TG-80A

Specifications:

Spray Booth Electric infrared lamp heating TG-80A
Inside dimension 6900*4000*2800 (LxWxH) Front door(mm) 3000*2700 mm(W×H)
Outside dimension 7050*5560*3650 (LxWxH) Total Power(Kw) 44 Kw
Cabin System Wallboard Rock wool colorful steel skin board, 75mm thick, steel 0.5mm thick,Compound construction, anti-flame and heat-insulation, galvanized steel roof panel.
Basement 350mm depth,Galvanized steel sheet and square steel pipe assembling, 2 rows of grid plates made by flat bar and round steel, 3 rows of diamond plates, galvanized. 2 ramps, external setting, 750 x 2000 mm ( W * L )/PC
Air Circulation System Intake Fan Blower Capacity: 25000m3/h Exhaust Fan Blower Capacity: 20000m3/h
Power: 7.5kw/PC, 970 rpm Power: 5.5kw/PC, 970 rpm
Quantity: 1 PC Quantity: 1 PC
Model: turbo fan Model: turbo fan
Air Volume: 25000m3/h, Air flow speed in the cabin: 0.25m/s
Heating system 10 units infrared curing lamps for heating, 3pcs of each unit, 1KW／pc. Total power: 30KW.
Filter system Dual-filtering structure Primary filter: Can Capture GranulesLarger than 10μm
Ceiling filter: 600g high efficiency filter, can Capture GranulesBigger than 4μm
Floor filter: fiberglass filter, exhaust activated carbon filter,Filtering rate> 95%, TSP≤1.4mg/m3
Lighting system Ceiling lights 8Units×4Pcs=32Pcs×36W> 900Lux, with anti-explosion design.
Side lights no
Control system Spraying, heat spraying, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop. All motors are full voltage start.
Environmental System Multi-Layer Fiberglasses Filter, active-carbon, and ensure a qualified exhaust according to the relevant state standards


TARGET Equipment is your best choose!

If you have any questions, plsContactwith our workers in anytime.
