Spherical Plain Bearings For Sewing Machine / C2 C0 C3 C4 C5 Thrust Rod End Bearings
Spherical Plain Bearings For Sewing Machine / C2 C0 C3 C4 C5 Thrust Rod End Bearings
Spherical Plain Bearings For Sewing Machine / C2 C0 C3 C4 C5 Thrust Rod End Bearings
Spherical Plain Bearings For Sewing Machine / C2 C0 C3 C4 C5 Thrust Rod End Bearings
Specifications
Place of Origin :
CHINA
Certification :
ISO9001、 OEM
Model Number :
GX20S
MOQ :
N/A
Packaging Details :
Poly bag + box into Carton + Plywood Case
Delivery Time :
Based on Detailed Order
Payment Terms :
T/T
Supply Ability :
Based on Detailed Order
Description

C2 C0 C3 C4 C5 Thrust Rod End Bearings / Spherical Plain Bearings For Sewing Machine

Quick Detail:

Thrust Rod End Bearings / Spherical Plain Bearings GX20S For Sewing Machine

Type: spherical plain bearing

Precision Rating: P0.P4 P5

Material: Chrome Steel ,Carbon steel,Stainles steel

Clearance: C2 C0 C3 C4 C5 as your required

Virbration Level: V1,V2,V3,as yor required

Noise rank: Z1,Z2,Z3

Place of Origin: China (Mainland)

Service: OEM service, customer design service and Buyer label service

Certificate: ISO9001:2008

Description:

Bearing number

d

(mm)

D

(mm)

B

(mm)

C

H

dk

S

d1 max

D1

min

A

α°

≈

Dynamic (kN)

Static

(kN)

Weight

≈Kg

GX20S

20

55

14.5

13.8

20

60

12.5

50

31

6

5

84

425

0.246

Joint bearing, thrust bearing inner and outer material is bearing steel, quenching, phosphating, coating mos2 sliding surface. The wear resistance, corrosion resistance, can make the characteristics of the applicable to carry axial load in single direction or by a combination of radial and axial load of mechanical institutions.

Applications:

1. Hydraulic Cylinders
2. Metal Forming Machinery

3. Construction Machinery

4. Automation Equipment

5. Auto Shock Absorbers

6. Hydraulic Machinery

Competitive Advantage:

1. High speed, High Precision, Low Noise, Long Service Life

2. Customers' drawing or samples accepted

3. Heavy radial loads and high speeds

4. Less vibration and noise

5. Small order accepted and sample accepted

6. Can withstand a little axial load if outer ring and inner ring have ribs

Other Sizes Available :

Type

Structure

Designation

Size Range (ID)

Radial

Fitting Crack

GE..E, GE..ES,GE..GE, GEF..ES

4-200mm

Wide Inner Ring

GEEW..ES

20-80mm

Two Pieces

GEXS/K, GEKXS

20-150mm

Inch Dimension

GEZ...ES, GEGZ...ES, GEWZ...ES

1/2"-6"

Maintenance-free

GE..C, GEG..C,GEE..T, GEX..T, GEGXT, GEZET

4-200mm

Angular Contact

Normal

GACS

20-200mm

Inch Dimension

GACZS

1/2"-6"

Maintenance-free

GACT

20-200mm

Thrust

Normal

GXS

20-200mm

Maintenance-free

GXT

20-200mm

Rod End

Combination

SI..E, SI..ES, SA..E, SA..ES

5-60mm

Maintenance-free

SIJKC, SIC, SAJKC, SAET, SAC

5-60mm

Inlaid Liner

SI..BPS, SA..BPS

5-60mm

Welding Shank

SK..ES, SF..ES

20-60mm

Ball Joint

One shank

SQD

5-16mm

Straight

SQZ

5-20mm

Winding Shape

SQ

5-20mm
