40 Tons 6 X 4 Semi Trailer End Dump Truck For Sand Stone Transportation
40 Tons 6 X 4 Semi Trailer End Dump Truck For Sand Stone Transportation
40 Tons 6 X 4 Semi Trailer End Dump Truck For Sand Stone Transportation
40 Tons 6 X 4 Semi Trailer End Dump Truck For Sand Stone Transportation
40 Tons 6 X 4 Semi Trailer End Dump Truck For Sand Stone Transportation
40 Tons 6 X 4 Semi Trailer End Dump Truck For Sand Stone Transportation
Specifications
Brand Name :
HOWO Brand
Model Number :
Tractor head trucks
Certification :
CE/ISO/BV/ADR/DOT
Place of Origin :
Shandong China(Mainland)
MOQ :
One Unit Tractor head trucks
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500Units per Month
Delivery Time :
20-30days after deposit
Packaging Details :
Nude package shipping by bulk cargo or Ro-Ro
Condition :
New
Usage :
Tractor head trucks
Drive stype :
6x4
Brand name :
Howo brand
Color :
Customized
Power :
309KW
By wheel :
4 WD
Size :
6800*2496*3563 mm
Price :
negotiation
Description

SINOTRUK HOWO tractor head trucks 6x4 40 tons Sand and stone rear Tipper Dump

FEATURES Tractor trailer trucks.

Luxurious, majestic and dynamic appearance.

--Latest international style cabin: Euro type cabin.

--Crystal and upright mounted headlamp

Reliable and high-security Design

--Lateral stability: Patent and tailored frame design

--Safety and reliability: New type break drum.

Low fuel consumption and high efficiency

--High efficiency Power-train: Optimized power transmission design

--Low wind resistance: Streamlined cabin design

Confortable

--Flat floor cabin, enlarge the driver’s space.

--Noise isolation technology

--Ergonomic trim and adjustable seats

--Tilted footstep on front bumper.

--Streamlined cabin design

--Ergonomic dashboard

Specification:

Cabin HOWO plat Cabin,one sleeper,Air suspension shock absorb seat ,
,Adjustable steering,air condition,bumper.windy deflector
Engine Diesel, 4-stoke direct injection,6-cylinder in line, Inner cooling,radiator, Turbo-charging
WABCO air compressor,two inlets cyclone air filter.
Model: Euro 2 STEYR technology CNHTC engine

MAX Horse power:

 336hp
Displacement(L): 9.726liter
Max torque: 1360NM@1400-1600rpm
Bore/stoke: 126mm/130mm
Fuel consumption: 195g /kwh
Gear box Model: HW15710 manual
Speed: 10speed,2 reverse
Max torque:1800NM Max Ratio:14.28
Axle(front/rear):
Front axle HF 7 ton Steyr technology non-driving steering axle. Drum brake
Rear and middle axle 13ton Steyr technology driving axle, hub redactor, double reduction
Clutch D430 diaphragm type,single dry frictional disc.hydraulic boosting.
Brake Service brake: Double circuit penumatic(air) brake
Parking brake: Spring-Power drum brake
Engine brake: Engine exhaust brake(EVB)
Steering

ZF 8098, driver sit at the left hand side
Electric Equipment
Operating voltage: 24V negative grounded
Starter 24V,5.4KW
Alternator 28V,1.5KW
Battery voltage 2X12V/135Ah
Frame Made of strengthened high intensity steel,parallel ladder with U-profiles,
Riveted cross members.
Tyre 295/80R22.5/6+1 spare tyre with rim
Suspension system: heavy duty leaf spring type
Front/Rear 10/12
Overall dimension(mm): 6110x2496x3668(Length x width x height)
Wheelbase 3500mm
Track: Front/Rear 2022/1830
Approach/Departure angle 16/42
Front /Rear overhang 1500/1110
Max speed 102km/h
Tare weight 7210kg Diesel tank: 400L


Tractor Head Trucks Models.

40 Tons 6 X 4 Semi Trailer End Dump Truck For Sand Stone Transportation

6x4 Stype Dump Trucks.

40 Tons 6 X 4 Semi Trailer End Dump Truck For Sand Stone Transportation

Welcome to China and visit our factory. We believe your smart choice will be rewarded with good quality and competitive price.
