TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
Specifications
Certification :
CE/ROHS/CPR EN50575/ISO9001 /ISO14001
Model Number :
TKQSFP-40G-SR4
Payment Terms :
T/T,Paypal
Price :
Can be negotiation
Supply Ability :
3000PCS/Week
MOQ :
1
Delivery Time :
5-9 Works depend on the QTY
Brand Name :
DF/OEM/Nuetral
Packaging Details :
Carton
Place of Origin :
ShenZhen & ZhongShan China
Description
TAKFLY 40G QSFP+ SR4 Transceiver

High-performance QSFP+ optical transceiver designed for 40GBASE-SR4 Ethernet, InfiniBand, and short-range multi-lane data communication applications. Featuring 4-channel parallel optics with 850nm VCSEL array, this module delivers 40Gbps bandwidth over multimode fiber, making it ideal for data center interconnects, high-performance computing (HPC), and enterprise network aggregation.

TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
Technical Specifications
  • 40Gbps aggregate bandwidth - 4 x 10.3125Gbps per channel
  • 4-channel full-duplex transceiver - simultaneous transmit and receive
  • 850nm VCSEL array - low power, high reliability, long life
  • 4-channel PIN photodetector array - high-sensitivity signal detection
  • 100m (OM3) / 150m (OM4) reach - over multi-mode fiber (MMF)
  • MTP/MPO-12 optical interface - standard 12-fiber ribbon connection
  • Hot-pluggable QSFP+ form factor - plug-and-play, no system shutdown
  • Low power consumption - <1.5W, +3.3V power supply
  • Built-in digital diagnostic functions - DDM/DOM for real-time monitoring
  • Housing isolated from connector ground - enhanced signal integrity
  • Wide operating temperature - 0°C to +70°C
  • RoHS-6 compliant - lead-free and environmentally friendly
  • IEEE 802.3ba compliant - 40GBASE-SR4 standard
  • QSFP+ MSA compliant - interoperable with major networking equipment
TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution TAKFLY 40G QSFP+ SR4 Transceiver – 850nm VCSEL, 100m/150m MMF, MPO-12, Short-Reach Data Center Solution
Manufacturing Excellence
26 Years of Manufacturing Experience in Fiber Optic Products
Experienced Assembly Team: More than 80 assembly workers with 6+ years of experience
Strong R&D Capability: More than 10 R&D engineers
Advanced Production Equipment: 16 sets of German imported injection machines and 16 production lines
Comprehensive Testing Facilities: More than 30 sets of testing instruments including OTDR, ILD, VFL, RL, IL, tension strength testers, crush resistance testers, power meter testers, and light checkers
OEM Branding Accepted: Custom logo/branding available
Quality Control Process
  • Incoming inspection: Spot check of raw materials before production
  • In-process inspection: Full inspection at every individual process completion
  • Pre-packaging inspection: Full inspection of finished products before packing
  • Pre-shipping inspection: Spot check before shipping
Industry Presence

Active participation in major industry exhibitions including:

Source Electronics Exhibition
OFC
FOCC
ConnecAsia
NFTCOM
AFRICACOM
SMART ICT
Contelem
Delivery Information
Samples 1-3 working days
Mass production orders 3-7 working days
Packaging Plastic bag, carton, and pallet options available according to your requirements
