600KVA UPS System Cabinet 60KW Pure Online Double Conversion for Power Supply
600KVA UPS System Cabinet 60KW Pure Online Double Conversion for Power Supply
Specifications
Price :
1000-10000USD
Delivery Time :
3-5 Days
Module Configuration :
60KW
Input Phase :
3-Phase + N + PE
Payment Terms :
T/T,Western Union
Topology :
High-frequency online double conversion, full digital DSP control
Cabinet Standard :
19-inch standard cabinet
System Rated Capacity :
600KVA
Model Number :
W-600KL
Packaging Details :
Pallet
MOQ :
1 Unit
Place of Origin :
China
Dimension (W×D×H) :
1600×1000×2200 mm
Parallel Function :
Max. 4 cabinets parallel, support N+1 / N+X redundancy
Protection Class :
IP20
Overload Capacity :
115% continuous; 125% for 10min; 150% for 1min
Brand Name :
BLAZING POWER
Certification :
CE
Supply Ability :
Stock
Power Factor :
1
Description
600 KVA UPS System Cabinet with Pure Online Double Conversion
Main Features
  • High-efficiency online double conversion technology
  • Excellent scalability for future expansion
  • Unity output power factor
  • Modular design reduces mean time to repair (MTTR)
  • Highly reliable operation with redundant power supply in static transfer switch (STS)
  • User-adjustable charging current
  • Easy installation and maintenance procedures
  • Flexible battery configuration for various applications
  • Strong overload capacity
  • 5.7-inch graphic LCD for simple management
  • N+1 or N+X parallel redundancy for power reliability
  • Optional 10-inch touch LCD panel available
Key Product Features
High Power Capacity with Redundant Reliability
Standard 600 kVA/600 kW output with modular design (typically 50 kW/60 kW power modules). Supports N+1 redundant operation and parallel capacity expansion for higher-power loads.
Pure Online Double Conversion with Zero-Interruption Switching
Zero-millisecond switching between utility and battery modes. Pure sine wave AC output provides complete isolation from grid disturbances. Ideal for sensitive equipment including precision industrial control systems, servers, and medical instruments.
High Efficiency and Energy Savings
Overall system efficiency ≥95% with high performance in light load conditions. Module sleep mode and intelligent cooling technology reduce energy consumption and operational costs. Compatible with both lead-acid and lithium-ion batteries.
Wide Input Voltage Range
Supports three-phase input voltage range of 208V-480V, suitable for harsh power environments including industrial grids, aging distribution systems, and remote areas. Reduces battery cycling and extends battery life.
Intelligent Monitoring and Protection
Standard LCD/touchscreen interface for real-time monitoring of voltage, current, load percentage, battery capacity, and system status. Supports remote monitoring (SNMP/Modbus) with comprehensive protection against electrical faults.
Integrated Design for Easy Deployment
Standardized cabinet design with built-in power distribution, bypass switches, and cooling systems. Power modules support hot-swapping for maintenance without power interruption, reducing operational complexity and downtime.
Quiet Cooling and Durable Operation
Intelligent variable-frequency air cooling with sealed, dust-proof design ensures controlled noise levels for data center environments. High protection rating suitable for industrial conditions with high humidity and dust.
