10KVA High Frequency UPS Zero Transfer Time Pure Sinewave Output
10KVA High Frequency UPS Zero Transfer Time Pure Sinewave Output
Specifications
Model Number :
W-10KL
Delivery Time :
3-5 Days
Frequency Range :
40-70Hz
Supply Ability :
Stock
Capcity :
W-10KL
Transfer Time :
Zero
Certification :
CE
Place of Origin :
China
Packaging Details :
Pallet
Waveform(Batt.Mode) :
Pure Sinewave
LCD :
YES
Brand Name :
BLAZING POWER
Battery DC :
192V
Weight :
15KG
Size :
442*190*318mm
MOQ :
1 Unit
Price :
300-500$ Unit
Payment Terms :
L/C,T/T,Western Union
Output Voltage :
380/400/415VAC (Phase-Phase)
Description
10KVA UPS: Zero Interruption Voltage Stabilization and Backup Power
This 10KVA online double-conversion UPS delivers pure sine wave output with zero transfer time, ensuring continuous power protection for critical applications.
Technical Specifications
Input/Output Configuration Three-phase five-wire (3P+N+PE), 380VAC Input
Single-phase three-wire (L+N+PE), 220VAC Output
Alternative Configuration Single-phase three-wire (L+N+PE), 220VAC Input & Output
Topology Online double-conversion, 0ms transfer, built-in static bypass
Power Rating 10KVA/8KW (PF=0.8) or 10KVA/9KW (PF=0.9)
Input Voltage 380V ±20% (280-478V)
Input Frequency 40-70Hz, auto-adaptive
Input Power Factor ≥0.99
Output Voltage 220/230/240VAC ±1%
Output Frequency Sync with mains; 50Hz ±0.1Hz on battery
Output THD ≤2% (linear load), ≤3% (non-linear load)
Overload Capability 125% for 60s, 150% for 10s, transfer to bypass
Efficiency ≥93.5% in online mode, up to 98% in ECO mode
Battery System 192/216/240VDC external battery pack
Communication RS232, USB, optional SNMP/Modbus
Key Features and Benefits
  • Powerful 10KVA/8KW online design supporting stable operation for servers, industrial control equipment, precision instruments, and server rooms
  • Double-conversion online technology provides voltage stabilization and uninterrupted power supply with zero-millisecond transfer during outages
  • Wide input voltage range adapts to harsh grid conditions, ensuring stable operation in industrial environments
  • Multi-level intelligent protection including overvoltage, undervoltage, overload, short circuit, overtemperature, and reverse battery connection safeguards
  • Pure sine wave output delivers clean, stable power compatible with all sensitive devices
  • LCD smart display for real-time monitoring of voltage, current, load percentage, battery capacity, and fault information
  • External battery configuration available to extend runtime from 10 minutes to over 8 hours
  • Compact and easy to install with rack-mount or tower configurations
  • Quiet operation with intelligent fan speed control, suitable for 24/7 continuous operation
Ideal Applications
Perfect for server rooms, workshops, retail stores, laboratories, medical equipment, and similar settings requiring reliable power protection.
