Flexible PCB Flexible Circuit Boards Double-Sided Printed Cable
High-performance flexible printed circuit boards designed for applications requiring superior flexibility, reliability, and space optimization.
Key Features & Benefits
  • Exceptional Flexibility: Can be bent, folded, and deformed freely with small coil radius and movement along X, Y, Z axes
  • Space Optimization: Light and thin design (average thickness 1.1-0.1mm) maximizes use of narrow instrument spaces
  • Lightweight Construction: Weight optimized based on current load requirements rather than mechanical strength
  • Superior Sealing Capability: Designed for low-tensile seal performance in adverse environments
  • Stable Signal Transmission: Freely designed wiring patterns and conductor distances ensure steady R, L, C parameters
  • Easy Assembly: Excellent terminal properties for soldering, inserting, riveting, and gluing applications
  • Advanced Insulation: Materials like polyimide and polyester provide excellent insulation properties
Material Composition
Copper Foil Substrate: Electrolytic or rolled copper (common thicknesses: 1oz, 1/2oz, 1/3oz)
Substrate Film: Common thicknesses 1mil and 1/2mil
Cover Film Protection: Surface insulation with thicknesses of 1mil and 1/2mil
Stiffener: PI stiffener film for mechanical strength reinforcement (3mil to 9mil thickness)
EMI Shielding: Electromagnetic shielding film for interference protection
Applications
  • Mobile Phones: Light weight and thin thickness save product volume, connecting battery, microphone, and buttons
  • Computers & LCD Screens: Single-line configuration converts digital signals into display images
Technical Specifications
Material PI: 1 mil, Cu: 1 oz, PI: 1 mil
Surface Treatment Pure-tin plating
Minimum Hole Dimension 0.3mm
Minimum Linear Width/Distance 0.08mm
External Tolerance +/-0.05mm
Welding Resistance 280°C for more than 10 seconds
Peeling Strength 1.2kg/cm²
Heat Resistance -200 to +300°C
Surface Resistivity 1.0 × 10¹¹
Bendability & Chemical Resistance Meets IPC standards
Competitive Advantages
  • Short Assembly Time: Complete line configuration saves extra wiring connection work
  • Small Volume: Effectively reduces product volume for enhanced portability
  • Light Weight: Lighter than rigid PCBs, reducing final product weight
  • Thin Profile: Thinner than hard PCB boards, improving flexibility and 3D assembly
  • Quick Delivery
  • Best Services
  • OEM/ODM Available
Membrane Switch Technical Specifications
Wire Lead Resistance <1Ω/CM Life Time >1 Million times
Rated Current 25-100mA, 0~30V DC Operation Temperature -104°F~158°F
Rated Voltage <50V, DC Operation Humidity at 104°F, <98% RH
Insulation Resistance <100MΩ, 250V DC Dome Springback Time <5 msec
Switch Travel Flat Type: 0.05-0.3mm
Tactile Type: 0.3-1.5mm		 Base Material Voltage Withstand 1500 V DC
Tail Flexibility Any angle within 180 degrees
