| Basic Information | |
| Model | CR17505 |
| Type | Lithium Manganese Dioxide Battery (LiMnO₂) |
| Voltage | 3.0V |
| Capacity | 3000mAh |
| Dimensions & Weight | |
| Dimensions | Diameter 17.5mm, Height 50.5mm (may vary slightly by manufacturer) |
| Weight | Approximately 30-40g |
| Electrochemical Performance | |
| Nominal Voltage | 3.0V |
| Discharge Cut-off Voltage | 2.0V |
| Charging Method | Non-rechargeable (Primary Battery) |
| Discharge Characteristics | Stable discharge voltage platform, suitable for low-power devices |
| Environmental Adaptability | |
| Operating Temperature Range | -20℃ to +60℃ (some models can reach -40℃ to +85℃) |
| Storage Temperature Range | -20℃ to +40℃ |
| Humidity Adaptability | Relative humidity 5% to 95% |
| Safety Features | |
| Over-discharge Protection | Built-in protection circuit |
| Short-circuit Protection | Equipped with short-circuit protection function |
| Leak-proof Design | Sealed structure to prevent electrolyte leakage |
| Other Features | |
| Self-discharge Rate | Low self-discharge rate, suitable for long-term storage and backup |
| Shelf Life | 3-5 years (under recommended storage conditions) |
| Certifications | Complies with international certification standards such as RoHS, CE, UL |
