IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.
IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.
IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.
IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.
IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.
IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.
IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.
IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.
Specifications
Brand Name :
TAC
Model Number :
IFR32700 8S5P
Certification :
MSDS UN38.3
Place of Origin :
CHINA
MOQ :
Allow negotiation
Price :
Allow negotiation
Delivery Time :
Allow negotiation
Packaging Details :
Allow negotiation
Description

IFM Pro 25.6V 30Ah Industrial Battery​

--Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.

IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.IFM Pro 25.6V 30Ah Industrial Battery​ – Powered by IFR32700 Cells, 8S5P, 768Wh. Built for AGVs, Robots & Solar Storage.

Product Specification(产品技术规格)

Table

No.

(序号)

Item

(项目)

General Parameter

(常规参数)

Remark

(备注)
1

Rated Capacity

(额定容量)

 30Ah

Standard discharge

0.2C after standard charge(0.2C)

(0.2C标准充电后0.2C标准放电)
2

Minimal Rated

Capacity

(最小容量)

 30Ah
3

Nominal Voltage

(标称电压)

 25.6V
4

Cycle Life

(循环寿命)

 Higher than 80% of the Initial Capacity of the Cells(初始容量的80%)

◆Charge: CC@0.2C to 29.2V, then CV till current to 0.02C

◆Rest: 30min.

◆Discharge: 0.2C to 20.0V

◆Temperature:20±5℃

◆Carry out 2000cycles

◆先以0.2C恒流充电至29.2V,再恒压充电至电流小于0.02C

◆搁置:30min.

◆放电: 0.2C放至20.0V

◆温度:20±5℃

◆循环2000次100%DOD
5

Discharge cut-off voltage

(放电截止电压)

 20V (放电保护电压)
6

Charging cut-off voltage

(充电截止电压)

 29.2V
7

Cell and assembly method

(电芯和组装方式)

 IFR32700-6.0AH 8S5P
8

Packing material

(外包装材料)

 PVC shrink
9

IR

内阻

 ≤150mΩ

No.

(序号)

Item

(项目)

General Parameter

(常规参数)

Remark

(备注)
9

Standard charge

(标准充电)

0.2C constant current(CC) charge to 29.2V,then constant voltage (CV)29.2V charge till charge current decline to ≤0.02C

0.2C恒流充电至29.2V,再恒压29.2V充电直至充电电流≤0.02C

Charge time : Approx 6h

(充电时间:大约6个小时)
10

Standard discharge

(标准放电)

Constant current 0.2C

Cut-off voltage 20.0V

(持续电流: 0.2C

截止电压:20.0V)
11

Maximum Charge Current

(最大充电电流)

 20A
12

Max Continuous Discharge Current

(最大持续放电电流)

 30A
13

Operation Temperature Range

(工作温度范围)

 Charge(充电): 0~45℃

60±25%R.H.
Discharge(放电): -20~60℃
14

Storage Temperature Range

(储存温度范围)

Less than 1 year : 0~25℃

(小于一年: 0~25℃)

60±25%R.H.

at the shipment state

(出货态时的湿度范围)

Less than 3 months:-5~35℃

(小于3个月:-5~35℃)
15

Weight

(重量)

 Approx/大约: 6.35kg
16

Pack Dimension

(包装后尺寸)

 Height/高度:76mm Max size
Width/宽度: 140mm
Length/长度: 351mm
