18650 Lithium Ion Cylindrical Battery
18650 Lithium Ion Cylindrical Battery
18650 Lithium Ion Cylindrical Battery
18650 Lithium Ion Cylindrical Battery
18650 Lithium Ion Cylindrical Battery
18650 Lithium Ion Cylindrical Battery
18650 Lithium Ion Cylindrical Battery
18650 Lithium Ion Cylindrical Battery
Specifications
Brand Name :
TAC OEM & ODM
Model Number :
ICR18650 1950MAH
Certification :
MSDS REACH ROHS
Place of Origin :
Shenzhen zhuhai
MOQ :
500 pcs for single cell , 50pack for battery packs
Price :
usd 2.2
Payment Terms :
100% prepaid before shipping out
Supply Ability :
100000PCS EACH WEEK
Delivery Time :
7-10 days after order confirm for stock model
Packaging Details :
meet UN38.3 Certification
material :
lithium ion
capacity :
2000mah
min capacity :
1950mah
circle life :
500 times
warranty :
1 year
size :
18*65mm
Standard charge :
0.2C
Standard discharge :
0.2C
weight :
40g
pvc color :
blue \ black \green or OEM
Description

18650 3.7V Lithium Ion Cylindrical Battery With CNS15364 Certification For Taiwan

Data for 18650 3.7V Lithium Ion Cylindrical Battery With CNS15364 Certification For Taiwan

No, Item General Parameters Remark
1 Rated Capacity Typical 2000mAh Standard discharge(0.2C)
Minimum 1950mAh After standard charge
2 Nominal Voltage 3.7V Mean Operation Voltage
3 Voltage at end of Discharge 3.0V Discharge Cut-off Voltage
4 Charging Voltage 4.2V Charge Cut-off Voltage
5 Internal Impedance less or equal to 70mΩ Internal resistance measured at AC 1KHz after 50%charge) The measure must uses the new batteries that within one week after shipment and cycles less than 5 times.
6 Standard charge Constant Current 0.2C5 A Constant Voltage 4.2V 0.01 C5A Cut off
7 Standard discharge Contant current 0.2C5 A end Voltage 3.0V
8 Fast Charge Constant Current 1.0C5 A Constant Voltage 4.2V 0.01 C5A cut off
9 Fast discharge Constant Current 1.0C5 A end Voltage 3.0V
10 Maximum Continous Charge current 1.0C5 A
11 Maximum Continous Discharge current 2.0C5 A
12 Operation Temperature range Charge:0~45 degree 60±25%R.H. bare cell
Discharge :-10~60 ℃
13 Storage Temperature range Less than 1 year: -20~25 ℃ 60±25%R.H. at the shipment state
less than 3 months:-20~40 ℃
less than 7 days:-20~60℃
14 Cell Dimension High:64.70±0.5mm Initial Dimension
Diameter:18.0±0.5mm

Features for 18650 3.7V Lithium Ion Cylindrical Battery With CNS15364 Certification For Taiwan

18650 Lithium Ion Cylindrical Battery

18650 Lithium Ion Cylindrical Battery
