Unmanned Aerial Vehicle battery pack 11.1v 35C 6000mah Polymer ion
Unmanned Aerial Vehicle battery pack 11.1v 35C 6000mah Polymer ion
Unmanned Aerial Vehicle battery pack 11.1v 35C 6000mah Polymer ion
Unmanned Aerial Vehicle battery pack 11.1v 35C 6000mah Polymer ion
Unmanned Aerial Vehicle battery pack 11.1v 35C 6000mah Polymer ion
Unmanned Aerial Vehicle battery pack 11.1v 35C 6000mah Polymer ion
Specifications
Brand Name :
TAC
Model Number :
11.1v 6000mah
Certification :
ROHS
Place of Origin :
guangzhou
MOQ :
500pcs
Price :
usd 29.5
Supply Ability :
10000 set/ month
Delivery Time :
25-28days
Packaging Details :
2 set/ inner box 5box / carton
Material :
polymer lithium ion
voltage :
11.1
capacity :
6000mah
discharge rate :
35C
Size :
28.5*44*166mm
cut off voltage :
9V
PCB :
with pcb
pvc color :
blue
Description

Unmanned Aerial Vehicle Battery Pack 11.1v 35C 6000mah Polymer ion

Quick Data

Nominal Capacity : 5000 mAh

Minimum. Capacity : 4900 mAh

Nominal Voltage 11.1 V

Charge Voltage: 12.6 ± 0.06V

Charge Current Standard charge: 0.5 C ( 2500 mA)

Charging Time Standard charge: 3.0 hours (Ref.) Rapid charge : 2.0 hours

Max. charge current 1.0 C ( 5A)

Cont.. Discharge Current 25.0 C ( 125A)

Max. Discharge Current 50.0( 250A)

Cutoff Voltage 9V

Resistance ≤ 10mΩ 1kHz AC Metho

Weight (Approx.) 400g

Standard Discharge Capacity

The standard discharge capacity is the initial discharge capacity of the cell, which is measured with discharge current of 2500MA with 9V cut-off at 25±5℃, within 1 hour after the standard charge.,

Standard Discharge Capacity

Cycle Life

Each cycle is an interval between the charge at CC-CV

500TIMES

Initial internal impedance measured at AC 1kHz after 50% charge.

Status of the cell as of ex-factory

The cell should be shipped in 50% charged state. In this case, OCV is not less than 11.4V

Packing

According to the lithium battery standard packing method. Put electrostatic bag packing after battery in a little box,then use carton packaging.

Storage Characteristics

Capacity after storage for 28 days at 25℃ from the standard charge, measured with discharge current

Capacity retention (after the storage) over 5000mah (85% of the capacity at 25℃)

Warranty:

Tac battery will be responsible for replacing the cell against defects or poor workmanship

for 12 months from the date of shipping. Any other problem caused by malfunction of the equipment or mix-use of the cell is not under this warranty.

Similar Model

No. Cell No. Pack Norminal Voltage(V ) Norminal Capacity(mAh) Continuous Discharge Burst Discharge Thickness ±0.2 mm Width ±0.5 mm Length ±1.0 mm Approx Weight (g)
1 683480SP-1500 3S1P 11.1V 1500 25 50 22.5 36 87 140
2 803496XP-2200 3S1P 11.1V 2200 35 70 26 35 105 195
3 8043125SP-4000 3S1P 11.1V 4000 25 50 26 45 132 315
4 883496SP-2600 3S1P 11.1V 2600 25 50 28.5 36 103 213
5 9543125SP-5000 3S1P 11.1V 5000 25 50 30.5 45 132 362
6 1043125SP-5000 3S1P 11.1V 5000 25 50 32 45 132 383
7 5543128SP-3200 3S1P 11.1V 3200 25 50 18.5 45 135 258
8 5043125SP-2500 3S1P 11.1V 2500 25 50 17 45 122 198
