Specifications
Payment Terms :
D/A,L/C,D/P,T/T
Customization Capabilities :
Supports Customization/MultipleUnits Splicing
Model Number :
D28
Countertop Material :
Q355 Steel/ Ht300 Cast Iron/Stainless Steel
MOQ :
1
Delivery Time :
15-25 work days
Exporting Country :
The Whole World
Model NO :
D28
Packaging Details :
4000mm*2000mm*300mm
Brand Name :
WUXI LEMAR
Thickness :
25mm
Place of Origin :
WUXI,CHINA
Verticality :
≤0.1mm/200mm
Price :
500USD-1500USD
Flatness :
≤0.1mm/1000mm
Supply Ability :
500 units/month
Payment Currency :
Dollar
Certification :
CE
Diameter :
28mm
Description
Flexible D28 Welding Table in Bridge Structure Welding
Flexible D28 Welding Table in Bridge Structure Welding
Product Overview
Flexible D28 Welding Table in Bridge Structure Welding

This Flexible D28 Welding Table is engineered for high-precision metal joining tasks, especially within bridge structure welding scenarios. Built with rigid steel substrate and nitrided surface treatment, the table features a standard D28 hole grid system for universal fixture mounting. Its flexible modular design allows fast reconfiguration of clamping positions to fit varied bridge component profiles. The flat tabletop maintains stable datum during long welding cycles, reducing assembly error and cutting setup time for heavy structural workpieces. It delivers reliable positioning accuracy and outstanding wear resistance under continuous heavy load workshop operations.

Product Parameters
Flexible D28 Welding Table in Bridge Structure Welding
Parameter Specification
Grid System D28 - 28mm holes on 100mm centers
Hole Tolerance 0.05 - 0.1mm
Tabletop Material HT300 cast iron / Q355 steel
Tabletop Thickness 100mm
Surface Treatment Nitrided (HV ≥ 600)
Flatness Tolerance ±0.1mm per m²
Static Load Capacity 5,000 kg per table
Standard Sizes 1500×1000, 2000×1000, 3000×1500mm
Leg Height 620mm (custom heights available)
Leg Construction 80×80mm square tube, 5mm wall
Leveling Feet M24 threaded, 50mm pad
Product Sizes
System Material Size(mm) Weight(kg)
D28/D16 HT300 cast iron/Q355 steel 1000*1000*200/150 300
D28/D16 HT300 cast iron/Q355 steel 1000*2000*200/150 520
D28/D16 HT300 cast iron/Q355 steel 1200*1200*200/150 400
D28/D16 HT300 cast iron/Q355 steel 1200*2400*200/150 800
D28/D16 HT300 cast iron/Q355 steel 1500*1000*200/150 420
D28/D16 HT300 cast iron/Q355 steel 1500*1500*200/150 600
D28/D16 HT300 cast iron/Q355 steel 1500*2000*200/150 800
D28/D16 HT300 cast iron/Q355 steel 1500*3000*200/150 1150
D28/D16 HT300 cast iron/Q355 steel 2000*3000*200/150 1500
D28/D16 HT300 cast iron/Q355 steel 2000*4000*200/150 2100
Product Advantages
Flexible D28 Welding Table in Bridge Structure Welding
  • Standard D28 hole matrix enables free combination of clamps and positioning blocks to accommodate diverse bridge structural workpieces.
  • Nitrided table surface reaches high hardness to resist scratches and welding spatter erosion for extended service life.
  • Ultra stable rigid steel body prevents table deformation under heavy weight during long hour welding fabrication.
  • Flexible layout adjustment shortens workpiece setup time and improves overall workshop production efficiency.
  • High positioning accuracy guarantees consistent assembly quality for large bridge steel components.
  • Compatible with most standard D28 series accessories for full modular expansion without extra modification.
Product Applications
Flexible D28 Welding Table in Bridge Structure Welding

The flexible D28 welding table serves as core fixture platform for bridge structure welding. It also applies widely in railway steel component fabrication, shipbuilding assembly, aerospace frame processing, heavy machinery manufacturing and general metal workshop custom welding projects.

Frequently Asked Questions
Q1: What material is this D28 welding table made of?
It is constructed using Q355 steel as the base material, with an optional nitrided finish for the working surface.
Q2: Can I customize the dimension of this flexible welding table?
Yes, custom table length and width are supported to match your workshop space and workpiece size.
Q3: What is the maximum load capacity per square meter for this table?
The rated load capacity is 3 ton per square meter under even workpiece placement.
Q4: Are D28 clamps and positioning accessories included in this product?
The package contains only the welding table. Related fixtures can be purchased separately.
Q5: How long can the nitrided surface resist welding spatter damage?
Proper usage maintains reliable surface performance for many years in heavy duty workshop environments.
Q6: Does the table keep flatness after repeated heavy load welding work?
The rigid base structure effectively controls deformation to preserve table flatness for long term use.
Contact Us

If you have demands for bridge structure welding or other metal fabrication projects, feel free to send your workpiece drawing and requirement details. Our professional engineering team will provide tailored fixture solution and competitive quotation for your business.
