The Precision 3D Modular Welding Fixture Table D16 is engineered specifically for small metal fabrication and precision assembly work. Built with high-strength Q355 steel and finished with professional nitriding treatment, this table delivers micron-level accuracy, exceptional durability, and unmatched versatility for delicate welding projects.

Using the standard 16mm hole system and a dense 50×50mm grid layout, the fine grid spacing enables millimeter-level adjustment and complex clamping solutions - making it an ideal workbench for processing small metal parts, thin sheet metals, and precision components.

• Ultra-High Precision D16 Hole System

  Industry-standard 16mm fixture holes on a dense 50×50mm grid with ± 0.05mm positioning accuracy. The fine pitch allows micron-level alignment for small and complex workpieces — no offset calculations, no guesswork, just precise clamping every time.

• Premium Nitrided Surface Treatment

  Professional nitriding creates a hard, protective layer with HV 550-650 hardness and 0.25-0.35mm depth. Benefits include:

  • Excellent resistance to welding spatter adhesion
  • Superior corrosion and scratch resistance
  • 5-10× longer service life than untreated steel
  • Easy cleanup and minimal maintenance
• Five-Sided CNC Machined Flatness

  Full CNC finishing on all 5 working surfaces (1 top + 4 sides) with ≤ 0.1mm/m flatness tolerance. Engraved grid lines and perimeter millimeter scales enable instant visual alignment — speeding up setup and eliminating measurement errors.

• 3D Modular Versatility

  Supports horizontal, vertical, and angled fixturing for complete 3D build capability. Fully compatible with all major D16 fixturing accessories: clamps, stop blocks, angle brackets, locating pins, V-blocks, and riser blocks. Build any fixture configuration in minutes.
