W21.8 RH Stainless Steel Pressure Regulator R11 Cylinder Connector PTEE
W21.8 RH Stainless Steel Pressure Regulator R11 Cylinder Connector PTEE
W21.8 RH Stainless Steel Pressure Regulator R11 Cylinder Connector PTEE
W21.8 RH Stainless Steel Pressure Regulator R11 Cylinder Connector PTEE
Specifications
Brand Name :
AFK
Model Number :
R11
Certification :
CE
Place of Origin :
China
MOQ :
1~10
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000PC
Delivery Time :
10
Packaging Details :
Expotrt Packing
After-sales service provided :
Online support
Material :
Stainless Steel,SS304/SS316L
Warranty :
1 Year
Application :
Industry Equipment
Key words :
Stainless Steel Pressure Regulator
Name :
Double Gauge Pressure Regulator
Description

Product Parameenters:

Maximum Inlet Pressure 500,3000psig
Outlet Pressure Ranges 0~25, 0~50, 0~50,0~250,0~500psig
Safety test pressure 1.5 times maximum inlet pressure
Operating Temperature -40°F to 165°F / -40°c to 74°c
Leakage Rate AgainstAtmosphere 2*10-8atm cc/sec he
Cv value 0.08

Materials:

Body 316L,Brass
Bonnet 316L. Brass
Diafragm 316L
strainer 316L(10mm)
Seat PCTFE,PTEE,Vespel
Spring 316L
Plunger valve core 316L

Application : 1.Laboratory 2.Gas Chromatography 3.Gas Lasers 4.Gas Bus-bar 5.Petrochemical Industry 6.Testing Equipment Design Feature: Single-stage pressure reducer Maternal and diaphragm use hard seal form Body NPT:1/4”NPT(F) The internal structure easy to purge Can set filters Can use a panel or wall mounting

W21.8 RH Stainless Steel Pressure Regulator R11 Cylinder Connector PTEE

Ordering Information

R11 L B B D G 00 02 P
Item Body Material Body Hole Inlet Pressure

Outlet

Pressure

 Pressure Guage

Inlet

size

Outlet

size

 Mark
R11 L:316 A D:3000 psi F:0-500psig G:Mpa guage 00:1/4″NPT(F) 00:1/4″NPT(F) P:Panel mounting
B:Brass B E:2200 psi G:0-250psig P:Psig/Bar Guage 01:1/4″NPT(M) 01:1/4″NPT(M) R:With relief valve
D F:500 psi K:0-50pisg W:No guage 23:CGGA330 10:1/8″ OD N:Needle calve
G L:0-25psig 24:CGGA350 11:1/4″ OD D:Diaphregm valve
J 27:CGGA580 12:3/8″ OD
M 28:CGGA660 15:6mm OD
30:CGGA590 16:8mm OD
52:G5/8″-RH(F)
63:W21.8-14H(F)
64:W21.8-14LH(F)

W21.8 RH Stainless Steel Pressure Regulator R11 Cylinder Connector PTEE

W21.8 RH Stainless Steel Pressure Regulator R11 Cylinder Connector PTEE
