6mm OD R11 Double Gauge Pressure Regulator N2 He 4000psi SS Pressure Regulator
6mm OD R11 Double Gauge Pressure Regulator N2 He 4000psi SS Pressure Regulator
6mm OD R11 Double Gauge Pressure Regulator N2 He 4000psi SS Pressure Regulator
6mm OD R11 Double Gauge Pressure Regulator N2 He 4000psi SS Pressure Regulator
6mm OD R11 Double Gauge Pressure Regulator N2 He 4000psi SS Pressure Regulator
6mm OD R11 Double Gauge Pressure Regulator N2 He 4000psi SS Pressure Regulator
Specifications
Brand Name :
AFK
Model Number :
R11
Certification :
CE
Place of Origin :
China
MOQ :
1~10
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000PC
Delivery Time :
10
After-sales service provided :
Online support
Material :
Stainless Steel,SS304/SS316L
Warranty :
1 Year
Application :
Industry Equipment
Product name :
Pressure Regulator
Key words :
Stainless Steel Pressure Regulator
Description

R11 Series stainless steel pressure regulator is Single-stage diaphragm, vacuum structure stainless diaphragm output. It has piston pressure reducing structure, constant outlet pressure, mainly used for high input pressure, suitable for purified gas, standard gas, corrosive gas etc..

Ordering Information

R11 L B B D G 00 02 P
Item Body Material Body Hole Inlet Pressure

Outlet

Pressure

 Pressure Guage

Inlet

size

Outlet

size

 Mark
R11 L:316 A D:3000 psi F:0-500psig G:Mpa guage 00:1/4″NPT(F) 00:1/4″NPT(F) P:Panel mounting
B:Brass B E:2200 psi G:0-250psig P:Psig/Bar Guage 01:1/4″NPT(M) 01:1/4″NPT(M) R:With relief valve
D F:500 psi K:0-50pisg W:No guage 23:CGGA330 10:1/8″ OD N:Needle calve
G L:0-25psig 24:CGGA350 11:1/4″ OD D:Diaphregm valve
J 27:CGGA580 12:3/8″ OD
M 28:CGGA660 15:6mm OD
30:CGGA590 16:8mm OD
52:G5/8″-RH(F)
63:W21.8-14H(F)

64:W21.8-14LH(F)

6mm OD R11 Double Gauge Pressure Regulator N2 He 4000psi SS Pressure Regulator

Product Parameenters:

Maximum Inlet Pressure 500,3000psig
Outlet Pressure Ranges 0~25, 0~50, 0~50,0~250,0~500psig
Safety test pressure 1.5 times maximum inlet pressure
Operating Temperature -40°F to 165°F / -40°c to 74°c
Leakage Rate AgainstAtmosphere 2*10-8atm cc/sec he
Cv value 0.08
