1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head
1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head
1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head
1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head
1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head
1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head
Specifications
Brand Name :
AFK
Model Number :
SF+PF
Certification :
CE
Place of Origin :
China
MOQ :
1~10
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000PC
Delivery Time :
1WEEK
Packaging Details :
Expotrt Packing
Material :
Stainless Steel,316L,Stainless steel 304 or 316,Stainless Steel304 316L
Shape :
reducing
Head code :
Hexagon
Connection :
Male,Female
Technics :
Forged
Medium :
Gas
Name :
Stainless Steel Tube Fittings
Size :
1/4" , 1" , 1/8" , 1/2" , 3/4"
Description

Short Description:

Model No.: SF+PF

Size: 1/8″, 1/4″, 3/8″, 1/2″, 3/4″ 1″ PT

Working pressure: 1000psi

Material: ss304

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Model SF

Socket-Female Thread

Part No. Female Thread Size T(pt) Dimensions (mm)
L Damx. d
21SF 1/8” 44.5 Φ25 Φ5
22SF 1/4” 50.0 Φ25 Φ7
23SF 3/8” 51.0 Φ25 Φ9
24SF 1/2” 54.5 Φ25 Φ9
44SF 1/2” 60.0 Φ35 Φ15
46SF 3/4” 60.0 Φ35 Φ15
48SF 1” 68.0 Φ35 Φ15
48SF 1” 68.0 Φ35 Φ15

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Model PF

Plug-Female Thread

Part No. Female Thread Size T(pt) Dimensions (mm)
L IDamx. d
21PF 1/8″ 33.0 H14 Φ7.5
22PF 1/4- 36,0 H17 Φ7.6
23PF 3/8″ 37.0 H19 Φ7.5
24PF 1/2- 40.0 H24 Φ7.5
44PF 1/2- 45.5 H24 Φ12
46PF 3/4″ 46.0 H30 Φ12
48PF 1” 51.5 H38 Φ12

Prodcut Display

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Corporate Style

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head
1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Projcet

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Installation items of pressure reducer

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Installation items of pressure reducer

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Gas supply installation project

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Gas supply installation project
The above is our company, the project, we are the gas Porter, we not only sell products, but also for customers to install services
