Industrial Automatic Screwdriver Machine Electric For Assembling Line
Industrial Automatic Screwdriver Machine Electric For Assembling Line
Industrial Automatic Screwdriver Machine Electric For Assembling Line
Industrial Automatic Screwdriver Machine Electric For Assembling Line
Industrial Automatic Screwdriver Machine Electric For Assembling Line
Industrial Automatic Screwdriver Machine Electric For Assembling Line
Specifications
Brand Name :
Waterun
Model Number :
WT7024-2Z
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD3800 ~ 6000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal, Credit Card
Supply Ability :
300 units per month
Delivery Time :
3-10 days
Packaging Details :
Auto screw tightening machine 94 X 94 X 95 cm 139kgs
Operating Range :
X240 * Y1/700 * X240 * Y2/700 * Z135mm（Double Z Axis）
Accuracy :
±0.02mm
Screwing Time :
1.0~1.5s/piece
Suitable Screw Size :
M1.5 ~ M4 (Total length no more than 20mm)
Dimensions(mm) :
1100 x 800 x 1620mm
Weight :
120kg
Description

Industrial Electric Screwdriver for Assembling Line Auto Screw locking machine

Applications:

1. Suitable for all kinds of consumer electronic products, such as mobile phones, cordless phones, calculators, navigators, audio, cameras, laptops, tablet computers, learning machines, small household appliances and so on.
2. Widely used in assembly of household appliances industry (electric kettles, air purifiers, hair dryers, televisions, air conditioners, washing machines, etc.)

Features:

1. Permanent magnetic suction (vacuum suction), to achieve fast feeding and screwing.

2. The operator can use manual positioning to do the programming. It is highly efficient and very easy to learn the operation.

3. With alarm function for fastening missing, untightened screws, worn thread, etc.

4. Support auto sensing start operation function.

5. With the fixed work table, the working position can be adjusted flexibly.

Industrial Automatic Screwdriver Machine Electric For Assembling LineIndustrial Automatic Screwdriver Machine Electric For Assembling Line




Specification:

Type WT7024-2Z
Locking screw range

X240 * Y1/700 * X240 * Y2/700 * Z135mm(Double Z Axis)
Screw time

1.0~1.5s/piece
Repeat accuracy ±0.02mm
Program record mode

15 files, each file can save up to 99 points
Control system

SCM + Touch Screen

Movement speed

X/Y Axis: ≤500mm/s, Z Axis: ≤300mm/s
Air source 0.4-0.6MPA
Working temperature 5-40℃
Working humidity 20-90%
Applicable screw size M1.5-M4(total screw length ≤ 20mm)
Dimension

1100 x 800 x 1620mm
Weight 120kg

Competitive Advantage:
Industrial Automatic Screwdriver Machine Electric For Assembling LineIndustrial Automatic Screwdriver Machine Electric For Assembling Line

Industrial Automatic Screwdriver Machine Electric For Assembling Line

Industrial Automatic Screwdriver Machine Electric For Assembling Line

We, Shenzhen Waterun Technology is established in 2003, located in Shenzhen, China. We are a leading manufacturer of Automated Equipmnets for electronic assembly industry. Our products include screw fasterning robot, soldering robot, glue dispensing robot, fume extractors etc.Waterun owns two factories and one business & logistric centor and nearly 100 employees. Due to the good quality and good pricing, our products are getting popular in many countries in the world. We have been supplying to a number of Global top 500 companies. Our's goal is to become the preferred and most trusted partner for global electroinc assembly industry.
