Specifications
Brand Name :
Waterun
Model Number :
B-800/B-A6
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD85 ~ 150
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal, Credit Card
Supply Ability :
10000 units per month
Delivery Time :
3-10 days
Packaging Details :
Dispensing Controller 51 X 30 X 72 cm 25.6kgs
Power Consumption :
8W/12W
Min.Dispensing Volume :
0.01ml/0.0001ml
Dimensions :
235 x 225 x 63mm
Weight :
2.2 Kg/3kg
Description

Automatic Dispenser Controller For Digital Camera Mechanical Components


Describtion :
Operated by a foot pedal switch and preset timer, this automatic liquid dispenser can dispense fixed amount of glue/soldering paste to determined
location via the needle and barrel.
Features:
Two controlling modes: manual mode & auto mode.
Precise control of dispensing drops and dispensing cycle.
Suck-back function ensures no leakage drops.
Designed for wide range of application: cellphone
key-press, printing, switch, connectors, computer, digital products, digital camera, MP3, MP4, electronic toys, horn, buzzer, electronic components, integrated circuit, LCD screen, relays, speaker, LED lamp, chassis bonding, ptical lens, mechanical components, seal, etc.
Work great for secure the SMD components position before soldering work.
Suitable for many different liquids, such a quick-drying glue, red glue, yellow glue, epoxide-resin glue, silica gel, grease, screw locking glue and soldering flux.
System comes with 3 30cc liquid barrels, 10 steel needle/tips and 10 plastic tips.

Product Details:

8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller

8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller

8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller

Model B-800 B-A6
Power 8W 12W
Air Source Max 0.99 Mpa Max 0.99 Mpa
Time Setting DIP switch 0.01-1s;0.1-10s；0.2-20s;0.3-30s 0.01~99.99s;0.001~9.999s
Control Mode Manual/Quantitative(fixed volume dispensing) Manual/16 freely set modes
Repetitive Accuracy ±0.05% ±0.01%
Dispensing Frequency 600/min >1000/min
Min. Dispensing Volume 0.01ml 0.0001ml
Dimension 235mm x 225mm x 63mm 235mm x 225mm x 63mm
Weight 2.2kg 3kg

Why Choose Us?

1.Good quality and competitive price.

2,Any Inquires will be replied within 24 hours.

3,All of our products 100% inspection before shipment, we guarantee to use our products safety.

4,OEM/ODM orders are warmly preferred.

5,We own the best after-sale service.Any problems occur,our team will do our best to solve for customers.

6,Faster delivery, sample order in stock, and 3-7 days after bulk production.

Our Company:


8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller

8W 12W Dispenser Controller Digital , Portable Paste Liquid Controller

We, Shenzhen Waterun Technology is established in 2003, located in Shenzhen, China. We are a leading manufacturer of Automated Equipmnets for electronic assembly industry. Our products include screw fasterning robot, soldering robot, glue dispensing robot, fume extractors etc. Waterun owns two factories and one business & logistric centor and nearly 100 employees. Due to the good quality and good pricing, our products are getting popular in many countries in the world. Our's goal is to become the preferred and most trusted partner for global electroinc assembly industry.
