PCB New UV Laser Depaneling System with Lower Stress On The Parts
PCB New UV Laser Depaneling System with Lower Stress On The Parts
PCB New UV Laser Depaneling System with Lower Stress On The Parts
PCB New UV Laser Depaneling System with Lower Stress On The Parts
Specifications
Brand Name :
ChuangWei
Model Number :
CWVC-5L
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Delivery Time :
15 days
Packaging Details :
plywood case
Colour :
White
PCB Material :
FR4, FPC
Laser Source :
Optowave UV
Name :
PCB Depaneling Machine
Description

New UV Laser Depaneling System with Lower Stress On The Parts

PCB New UV Laser Depaneling System with Lower Stress On The Parts

Advantages of Laser PCB depaneling/singulation

  • No mechanical stress on substrates or circuits
  • No tooling cost or consumables.
  • Versatility – ability to change applications by simply changing settings
  • Fiducial Recognition – more precise and clean cut
  • Optical Recognition before PCB depaneling/singulation process begins.
  • Ability to depanel virtually any substrate. (Rogers, FR4, ChemA, Teflon, ceramics, aluminum, brass, copper, etc)
  • Extraordinary cut quality holding tolerances as small as < 50 microns.
  • No design limitation – ability to cut virtually and size PCB board including complex contours and multidimensional boards

Specification

Parameter

Technical parameters

 Main body of laser 1480mm*1360mm*1412 mm
Weight of the 1500Kg
Power AC220 V
Laser 355 nm
Laser

Optowave 10W(US)
Material ≤1.2 mm
Precision ±20 μm
Platfor ±2 μm
Platform ±2 μm
Working area 600*450 mm
Maximum 3 KW
Vibrating CTI(US)
Power AC220 V
Diameter 20±5 μm
Ambient 20±2 ℃
Ambient ＜60 %
The Machine Marble
CE approval
PCB New UV Laser Depaneling System with Lower Stress On The Parts
Production flow
PCB New UV Laser Depaneling System with Lower Stress On The Parts
More information welcome to contact us:

WhatsApp/Wechat(Bunny): +86 136 8490 4990

www.pcb-soldering.com

Email:s5@smtfly.com

www.pcb-depanelizer.com
