Specifications
Place of Origin :
Guangdong, China
Supply Ability :
400000pcs per month
Type :
GPS/GNSS Antenna
VSWR :
<1.5
Frequency :
1575.42Mhz
Connector :
TRS or USB or others
IP Rank :
IP65/IP67
Model Number :
RDYLGM-5
Name :
GPS Antenna
Mounting Method :
Adhesive or Magnetic
Gain :
28dBi
Protocol :
TTL or RS232 or others
Brand Name :
RIDA Antennaer
Packaging Details :
opp bag single pcs
Cable Length :
1000mm
MOQ :
10
Delivery Time :
10-15days
Certification :
ISO9001/IATF16949
Description
RX TX GND VCC 4 pin 3 pin RS232 RS485 RS422 TTL 1575.42MHz GPS Receiving Antenna G-mouse Module Antenna Customization scope:Antenna performance, Appearance, Cable length, Connector type
Products Description
RX TX GND VCC 4/3-Pin RS232 RS485 RS422 TTL 1575.42MHz GPS Receiving Antenna G-mouse Module 28dBi Gain IP65/IP67 RIDA Antennaer
Product Description
The HTGNSS HT-268M7Series with embedded GPS antenna enables high performance navigation in the most stringent applications and solid fix even in harsh GPS visibility environments.
It is based on the high performance features of the MediaTek single-chip architecture, Its–165dBm tracking sensitivity extends positioning coverage into place like urban canyons and dense foliage environment where the GPS was not possible before. The connector design is the easiest and convenient solution to communication with other electronic equipment.
Product Application
• Handheld GPS receiver application
• Ideal for PDA, Pocket PC
• Geographic Surveying
• Sports and Recreation
• Marine Navigation,Fleet Management
• Automotive application
• Car navigation and tracking
• AVL andLocation-Based Services
• Timing application
• UAV
Features
• Ultra high sensitivity:-165dBm
• 22tracking/66 acquisition-channel receiver
• WAAS/EGNOS/MSAS/GAGAN support
• NMEAprotocols(default: 9600bps)
• Internal back-up battery
• Embeddedpatchantenna 25x25x4.0mm
• Operating temperature range:-40 to 85℃
• RoHScompliance(Lead-free)
• Tinyform factor :45.5* 38.5 * 14.5mm
We also have a 3 PIN version
Product Parameters & Customizable Range
Frequency range(MHz)
1575.42MHz
Impedance
50Ω
V.S.W.R
≤1.5
Gain
28 dBi
Polarization type
R.H.C.H
Power Capacity
50W
Connector
TRS/USB or others
Radome Color
Black
Radome Material
ABS
Cable length
1000mm
Voltage
DC 3.3-5.0V
Working Temp(°C)
-40°C~+85°C
