Specifications
Certification :
ISO9001/IATF16949
MOQ :
20
Model Number :
RDYLC-1
VSWR :
<1.5
Service :
OEM/ODM
Frequency :
698-2700 MHz 1561/1575.42/1602
Supply Ability :
400000pcs per month
LNA Gain :
28dBi
Impedance :
50Ω
Brand Name :
RIDA Antennaer
Connectivity :
Fakra
Type :
GPS/GNSS Antenna
Cable Length :
3M(Customizable)
Antenna size :
60*13mm
Installment :
adhesive
Polarity :
vertical
Applied technology :
GPS GLONASS BEIDOU 4G 5G WIFI
Material :
PC
Place of Origin :
Guangdong, China
Packaging Details :
opp bag single pcs
Delivery Time :
10-15days
Description

Product Parameters
GNSS specifications

Center Frequency *
1575.42MHz±3 MHz / 1561MHz / 1602MHz
V.S.W.R
<1.5
Band Width
±5 MHz
Attenuation
fo±100MHz>30dB
Impendence
50 Ω
Peak Gain
>3dBic, Based on 7×7cm ground plane
Gain Coverage
>-4dBic at –90°<0<+90°(over 75% Volume)
Polarization
Right-handed Circular(RHCP)
LNA Gain(Without cable) *
28dBi
Noise Figure
1.5dB
V.S.W.R
<1.65
DC Voltage
2.7V-5.0V±0.5V
DC current
15mA Max(5V DC)
2G/3G/4G/5G specifications

Frequency Range *
600-6000MHz
V.S.W.R
<1.5
Band Width
±90/280 MHz
Gain *
3.0dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
2.4/5.8Ghz WIFI specifications

Frequency Range *
2300-2500/5700-5900MHZ
V.S.W.R
<1.5
Band Width
±100 MHz
Gain *
3.0dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
