Specifications
Material :
ABS or PC as requirement
Brand Name :
RIDA Antennaer
Model Number :
RDYLC-1
Frequency :
GPS GLONASS BEIDOU 4G 5G WIFI
Service :
OEM/ODM
Connectivity :
as requirement
Price :
RM 9.26-12.07
Cable Length :
3M(Customizable)
VSWR :
<1.5
Polarity :
vertical
LNA Gain :
28dBi
Connector :
Fakra/MMCX/Customized
Impedance :
50Ω
Place of Origin :
Guangdong, China
MOQ :
20
Type :
GPS/GNSS Antenna
Description
Products Description
Automotive Combo Antenna for GPS GNSS GPS WIFI 2.4G 5.8G GSM LTE 5G 4G 3G 2G LoRa 433Mhz 868Mhz 915Mhz Phone Signal High
Automotive Combo Antenna for GPS GNSS GPS WIFI 2.4G 5.8G GSM LTE 5G 4G 3G 2G LoRa 433Mhz 868Mhz 915Mhz Phone Signal High
Automotive Combo Antenna for GPS GNSS GPS WIFI 2.4G 5.8G GSM LTE 5G 4G 3G 2G LoRa 433Mhz 868Mhz 915Mhz Phone Signal High

Waterproof, corrosion and high temperature resistance tests, comprehensive quality inspection reports. Ensure the normal use of the product in various environments.
(For more test reports, please contact)

Product Parameters
GNSS specifications

Center Frequency *
1575.42MHz±3 MHz / 1561MHz / 1602MHz
V.S.W.R
<1.5
Band Width
±5 MHz
Attenuation
fo±100MHz>30dB
Impendence
50 Ω
Peak Gain
>3dBic, Based on 7×7cm ground plane
Gain Coverage
>-4dBic at –90°<0<+90°(over 75% Volume)
Polarization
Right-handed Circular(RHCP)
LNA Gain(Without cable) *
28dBi
Noise Figure
1.5dB
V.S.W.R
<1.65
DC Voltage
2.7V-5.0V±0.5V
DC current
15mA Max(5V DC)
2G/3G/4G/5G specifications

Frequency Range *
600-6000MHz
V.S.W.R
<1.5
Band Width
±90/280 MHz
Gain *
3.0dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
2.4/5.8Ghz WIFI specifications

Frequency Range *
2300-2500/5700-5900MHZ
V.S.W.R
<1.5
Band Width
±100 MHz
Gain *
3.0dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
