Access Control System High Aluminum Electric Bolt Lock For Glass Door
Access Control System High Aluminum Electric Bolt Lock For Glass Door
Access Control System High Aluminum Electric Bolt Lock For Glass Door
Access Control System High Aluminum Electric Bolt Lock For Glass Door
Access Control System High Aluminum Electric Bolt Lock For Glass Door
Access Control System High Aluminum Electric Bolt Lock For Glass Door
Access Control System High Aluminum Electric Bolt Lock For Glass Door
Access Control System High Aluminum Electric Bolt Lock For Glass Door
Specifications
Brand Name :
JUNSON
Model Number :
JS-1502SLD
Certification :
CE/ROHS/FCC
Place of Origin :
China
MOQ :
10pcs
Price :
negotiation
Payment Terms :
T/T, paypal or western Union in advance
Supply Ability :
30,000pcs per month
Delivery Time :
2-7 working days after received your payment
Packaging Details :
Packed in carton
Product Name :
electric bolt lock
Type :
Fail safe
starting current :
12VDC/1.3A , 24VDC/0.5A
Timer adjuster :
0-6S
Application :
frameless glass door
Time :
0-6s
Signal out :
N/A
Open sensor :
magnet switch sensor
Description

High Aluminum Electric Bolt Lock For Access Control System

Frameless glass door ,glass door , wooden door , metal door Electric bolt Lock . We supply integrity equipment to collocate with fully frameless glass door . Build-in Photo electricity control and low tempreture design .

Feature

▶Low Temperature, safe & Durable

▶Low Power, Environmental Protection

▶MOV Provides Reverse Current Protection

▶Special Designed Solenoid for Strength and Long Life with 500000 Operations

▶Superior Strength Aluminum Alloy, Solid Stainless Steel Bolt

▶CE Certificate by European Union, MA China Public Security office

Specification:

Fail Safe: unlock when power off
Material size: Zinc alloy
Signal output No/Nc/Com
Magnet bracket: 148L*43W*39H(mm)
Lock pin: 12mmDIA,stainless steel out throw15mm
Voltage: DC12V / 24V (customize )
Current:

Start: 1.3A

Standby: 0.08A
Holding force 1000kg
Solenoid: Continuous duty
Auto relock Timer jumper adjustable (0/3/6S)
Surface Temp: ≦20℃
Induction Distance 8mm
Operating temp: -10~+25℃(14-131F)
Operating Humidity: 0~90%(non-condensing)
Face place material: 3mm thickness stainless steel
Weight: 1.2kg
Standard Packing: 10pcs.
Carton size: 53Lx29Wx14H(cm)

Access Control System High Aluminum Electric Bolt Lock For Glass Door
Access Control System High Aluminum Electric Bolt Lock For Glass Door
Access Control System High Aluminum Electric Bolt Lock For Glass Door
Quality Guarantee :

Warranty Service will be honored if the damage is not caused by human, JUNSON Provides 2 years warranty for relative products. On the contrary, JUNSON will charge extra if repair. More information, please browse our service center.
We offer many Electronic lock, like: Magnetic door lock, Electric deadbolt lock, Electric strike, Electric bolt lock, Electronic lock.
