Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner
Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner
Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner
Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner
Specifications
Brand Name :
SZ
Model Number :
HDPE LDPE LLDPE
Certification :
ISO
Place of Origin :
CHINA
MOQ :
30000 square meters
Price :
$0.3-$2.0/SQM
Payment Terms :
T/T,L/C
Supply Ability :
100 Tons per day
Delivery Time :
5-8 days
Packaging Details :
Packed in woven bag or your requirements
Product Name :
Anti-seepage ASTM HDPE Geomembrane
Thickness :
100Mil 2.5mm
Application :
Wastewater Treatment Plant
Function :
Anti-seepage Waterproof
Material :
HDPE LDPE LLDPE
Type :
Smooth or Textured
Length :
50m-200m
Width :
1m-8m
Description

Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner

Yixing Shenzhou HDPE Geomembrane


1.Main Thickness:0.2mm,0.3mm,0.5mm, 0.75mm,1.0mm,1.5mm,2.0mm,3.0mm,4.0mm,5.0mm
2.Main Width:4m, 5m, 5.8m, 6.0m, 7m, 8m,10m
3.Main Length:50m/100m/150m/200m
4.Main Color: black, white, blue, green
5. Optional surface: Textured or Smooth surface.
6.Material:HDPE, LDPE,LLDPE,EVA
7. Certificate & Test: ISO, TRI, SGS
8. Quality Control: Third party test and factory lab test

Yixing Shenzhou HDPE Geomembrane For Wastewater Treatment Plant


1. Primary/Secondary Containment
Anaerobic digesters
Aeration tanks
Sludge thickening ponds

2. Specialized Structures
Effluent storage lagoons
Biosolid drying beds
Odor control covers

3. Safety Systems
Emergency overflow ponds
Stormwater retention basins
Leachate collection pads

Yixing Shenzhou HDPE Geomembrane for Sewage Treatment Advantage


Our HDPE geomembranes provide absolute liquid containment for urban sewage treatment facilities, preventing groundwater contamination while withstanding aggressive wastewater environments. The smooth surface facilitates sludge removal and maintenance.

Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond LinerWastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner

Waterproof HDPE Geomembrane Sewage-Specific Installation Protocol

  1. Subgrade Preparation

    • 95% Proctor compaction

    • Geotextile protection layer (300g/m² recommended)

  2. Welding Requirements

    • Dual-track hot wedge seams

    • 100% seam testing (spark/vacuum)

  3. Anchoring System

    • Termination trenches with polymer anchors

    • Overflow pipe penetrations with boot details

No. Properties Test Method Test Value
1 Thickness(mm) ASTM D5199 0.50 0.75 1.00 1.25 1.50 2.00 2.50 3.00
2 Density (g/cm2) ASTM D1505 0.939
3 Tensile Propeties
Yield Strength(N/mm) ASTM D6693 7 11 15 18 22 29 37 44
Break Strength(N/mm) 13 20 27 33 40 53 67 80
Yield Elongation % Type IV 12
Break Elongation % 700
4 Tear Resistance/N ASTM D1004 62 93 125 156 187 249 311 374
5 Puncture Resistance/N ASTM D4833 160 240 320 400 480 640 800 960
6 Stress Crack resistance/hr

ASTM D5397

(App.)

 300
7 Carbon Black
Carbon Black Content % ASTM D1603 2.0-3.0
Carbon Black Dispersion ASTM D5596

Carbon black dispersion(only near spherical agglomerates)for 10 different views 9

in categories 1 or 2 and 1 in category 3
8 Oxidative Induction Time(OIT)
Standard OIT/min ASTM D3895 100
High Pressure OIT/min ASTM D5885 400
9 Oven Aging at 85°C
Standard OIT-% retained after 90 days ASTM D3895 55
High pressure OIT-% retained after 90 days ASTM D5885 80
10 UV Resistance
Standard OIT retained after 1600 hrs ASTM D3895 50
High pressure OIT retained after 1600 hrs ASTM D5885 50
11 Low tempreture impact brittle property at -70°C _ Pass
12 Permeability g·cm/(cm2)·Pa _ ≤1.0×10-13
13 Dimensional Stability/% _ ±2
