Bottom Lining And Anti-seepage 2.5mm 100Mil ASTM HDPE Geomembrane Tailings Treatment Mine Industry

Yixing Shenzhou HDPE Geomembrane For Tailings Treatment Mine Industry ,

The application of 2.5mm anti-seepage geomembrane in the tailings industry is mainly based on its excellent physical properties and durability. It is especially suitable for tailings ponds with high corrosion,

high pressure and complex geological conditions.

Such as Super strong physical indicators :

Thickness tolerance: ±0.15mm (GB/T17643 standard)

Tensile strength: longitudinal ≥34MPa, transverse ≥31MPa

Right-angle tear force: ≥160N (ASTM D1004)

Chemical stability: such as pH value, heavy metal ions, etc.

Yixing Shenzhou HDPE Geomembrane Types:

1. Main Thickness:0.2mm,0.3mm,0.5mm, 0.75mm,1.0mm,1.5mm,2.0mm,3.0mm,4.0mm,5.0mm
2. Main Width:4m, 5m, 5.8m, 6.0m, 7m, 8m,10m
3. Main Length:50m/100m/150m/200m
4. Main Color: black, white, blue, green
5. Optional surface: Textured or Smooth surface.
6. Material:HDPE, LDPE,LLDPE,EVA
7. Certificate & Test: ISO, TRI, SGS
8. Quality Control: Third party test and factory lab test

Waterproof HDPE Geomembrane Application And Uses

 1. Environmental protection and environmental sanitation 2. Water conservancy 3. Municipal projects 4. Mine industry  5. Traffic facilities 6. Agriculture  7. Animal husbandry 8. Aquaculture  9. Landscape garden  10. Petrochemical industry  11. Salt industry

HDPE Geomembrane Tailings Treatment Installation Protocol Critical Steps:

Subgrade Prep

≤2% slope gradient
300mm compacted clay layer (k≤1×10⁻⁷ cm/s)

Welding
Dual-track hot wedge: 2×10mm weld width
Field seams: ≥1.5m overlap at slopes >25°

Protection Measures

500g/m² nonwoven geotextile cushion layer
200mm drainage gravel above liner
